Starrett 196a6z Dial Indicator With Magnetic Base

US $140

Newburgh, New York, United States
May 30th

Open on mobile:
QR code

PRODUCT DETAILS Universal Back Plunger Dial Indicators: .200", 5MM Our 196 Indicator is one of the most versatile indicators available ... and it is the "granddaddy" of them all. Over the years this tool has been improved by methods and materials, but the basic design is unchanged. The design has withstood the test of time and beaten all challengers because it is: • Accurate and reliable • Simple to operate • Rugged, with few moving parts • Smooth in operation While there is a need for indicators with finer graduations, such as our 708 Indicators, this indicator with graduations to .001" and 0.02MM will handle by far the majority of jobs. Shank diameter is 1/4" (6.3MM). Antimagnetic models are also available: (inch reading) 196A6Z and 196B6. For full use, the operator first chooses the proper contact from the three hardened contact points that come with each model. Then the contact should be brought against the work with enough pressure to give the hand one full turn. Set the hand at zero by rotating the dial with the knurled bezel. This provides one full rotation of the hand both to the right and left of zero, showing a rise or drop in the work and the amount of that variation. Inch Reading - 1/4 Inch Shank Diameter Graduation Range Dial Reading Description Catalog No. .001 Inch .200 Inch 0-100 Indicator with 3 Contact Points, Adapter, 4 Attachments* in Case 196A1Z Indicator with 3 Contact Point and Adapter Only 196B1 Indicator with 3 Contact Points, Adapter, with Standard Letter of Certification 196B1 W/SLC Antimagnetic Indicator with 3 Contact Points, 4 Attachments* in Case 196A6Z Antimagnetic Indicator with 3 Contact Points Only 196B6 0-50-0 Indicator with 3 Contact Points, Adapter, 4 Attachments* in Case 196A5Z Indicator with 3 Contact Points and Adapter Only 196B5 Millimeter Reading - 6.3 mm Shank Diameter Graduation Range Dial Reading Description Catalog No. 0.02 mm 5 mm (in 2-1/2 rev. of the hand) 0-100 Yellow Dial Face Indicator with 3 Contact Points, Adapter, 3 Attachments* in Case 196MA1Z Indicator with 3 Contact Points Only 196MB1 0-50-0 Yellow Dial Face Indicator with 3 Contact Points, Adapter 196R, 4 Attachments* in Case 196MA5Z Indicator with 3 Contact Points and Adapter Only 196MB5 *Attachments include clamp, tool post holder, snug and hole attachment.
