Steam Trap Tester, Check-it Electronics 0616 Digital Testing Pyrometer

US $120

Huntington, Indiana, United States
May 30th

Open on mobile:
QR code

Nice Item: Bought but never used ...The CHECK-IT Model 0616 Steam Trap Tester allows you to accurately and quickly measure pipe temperatures at the upstream and downstream sides of a steam trap. Armed with such accurate readings, you can instantly determine whether or not a steam trap is malfunctioning. With a temperature range of -100°F to 1999°F, this pocket size tester comes in a self-containing high impact case holding a quick response CHECK-IT 04260276 surface probe and a 9 volt battery. The CHECK-IT 0616 Digital Steam Trap Tester is easy to read since it incorporates a large .5" liquid crystal display which is updated 1.5 times per second. Remember . . . when a steam trap malfunctions, overall system efficiency decreases and escaping steam produces energy loss. FEATURES Built for Reliability Designed especially for Steam Trap Testing Readings instantaneous - NO DELAY Detects malfunctioning traps instantly Stainless Steel probe with 3 ft. retractable cord, for hard-to-reach areas Conveniently packaged for all field use ON/OFF switch recessed - No accidental turn on to waste batteries! Super sensitive probe responds instantly to the hottest or coldest temperatures Operates on one 9V battery, 1 year life in normal use Increases efficiency and decreases energy loss Large 0.5 inch LCD display: read-out visible even in direct sunlight Open probe indication Low battery indication One full year warranty Made in the United States of America SPECIFICATIONS Range: -100° to 1999°F Accuracy: -100° to 1000°F, ±1° Rsolution: 1°F Repeatability: 1°F Operating temperature: -10° to 55°C ambient Power: One 9V battery, Approximately 1000 hours life Sensor: Type K thermocouple Probes: Usable to 1999°F Intermittent, 1200°F Continuous Chord Retractable 9 inches extends to 3 ft. Connector: Phono Type Warranty: One full year Storage Temperature: -20°C to 60°C at 40% relative humidity Size: 7-1/4" x 3-5/8" x 1-1/8" Weight: (including battery) Approximately 10 ounces Display: 0.5" high liquid crystal (LCD) Case: Drop-proof black molded case READINGS CHART The table shows that for an upstream pressure of 150 psig, a pyrometer reading between 329°F and 348°F should be obtained. And for a down stream steam pressure of 15 psig, a pyrometer reading of between 225°F and 238°F is desirable. We can conclude, therefore, that the trap is functioning properly. PIPE SURFACE TEMPERATURE vs. STEAM PRESSURE Steam Pressure (PSIG) Steam Temp. (°F) Pipe Surface Temp. (°F) 15 250 225-238 50 298 268-283 100 338 304-321 150 366 329-348 200 388 349-369 450 460 414-437 *****PAYMENT/SHIPPING***** PAYPAL,cash on local pick-up or email me on other type of payment. Payment is expected within 3 days of auction close... Most of my items are shipped thru USPS *****TERMS OF SALE***** All returns are charged a 15% restocking fee.
