Stedi16x Spi Serial Board Module 16 Digital Inputs For Arduino, Raspberry Pi

US $19.90

Sofia, Sofia, Bulgaria
Mar 13th

Open on mobile:
QR code

STEDI16X Expansion board with 16 Digital Inputs SPI / Serial command port 16 Digital Inputs 0..30V, Active level L, connection to GND 74HC165 based logic Can be managed from 3.3 … 5V logic Power Voltage: +12V,+5V, +3.3V Power Current: 2mA Dimensions: 162 x 60 x 20 mm Weight: 60 gr Board application This board adds 16 digital inputs to your controller (Arduino, Raspberry Pi and similar). It is managed through a serial interface, typically SPI. You can connect multiple boards sequentially according to your needs. You can combine different models of our boards. The board uses a minimum number of wires for the control, only 3 - Data, Clock, Latch. The board is designed to loads minimal your controller. Input current is resistor 22k to GND (0.23mA for 5V VDD) for Clock, Latch and same to VDD for Input. You can use this board to obtain +5V for your board from +12V Voltage. Command port This controller is based on 74HC165. Practically you read the register. It is desirable that the wires between the boards to be minimal short. This affects the maximum speed at which you can maintain stable communication. There are no other limits for speed. You can connect ALL our Expansion boards (STEDOxx/STEDIxx) to a single SPI port. Download / Document / Software Hardware 74HC165 Datasheet Payment method Only Paypal Item will be shipped to Paypal address. Please confirm your shipping address in the PayPal Account. Return Policy Please be advised that shipping and handling cost are not refundable. Refund will be sent after we received your returning item. In all cases, buyers pay shipping at their own cost to return products for refund. Shipping Normally, We ship order within 24 hour from Monday to Saturday after the payment is cleared. Combine Shipment - YES. Ask for TOTAL, BEFORE you pay. Once you pay, we cannot make a discount for shipping. The shipping time may vary, depends on receiver's location. Item will be shipped WITH tracking number. Item Declare Your item will be mark as Gift or at a low's value. However, most of our items can reach to buyers without any taxes. We are NOT responsible for any import tax, customs fees or customs delay.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Expansion SPI Serial board module
Country/Region of Manufacture	Bulgaria
Model	STEDI16X
Country of Manufacture	Bulgaria
MPN	STEDI16X
