Stepper Motor Speed Pulse Controller & Driver Board Gbw

US $13.63

  • Shanghai, China
  • Jan 29th
Open on mobile:
QR code
Search HOME DESCRIPTION Stepper Motor Speed Pulse Controller & Driver Board GBW Product Description Specifications: Matching motors: 6 wires or 4 wires stepper motor (2-phase) Amperage: <2A Voltage (board): 5VDC Voltage (stepper motor): 9-40VDC Motor speed adjustable and can be retained Motor Wire Connections: A+ to A A- to B B+ to C B- to D Common Empty if 6-wire motor Pulse and Signal Control Mode: Remove jumper JP1 Input pulse: CP (can adjust step motor speed) Directional signal: DIR (high voltage=INC; low voltage=DEC) Button Control Mode: Mount jumper JP1 With jumper JP2 mounted: INC=CW run, DEC=CCW run, FUN=Stop With jumper JP2 removed: INC=Accelerate, DEC=Decellerate, FUN=Speed memory If you mount jumper JP2 after speed adjustment it will be memorized, even when power is off Dimensions: Width 46mm (1.8in), Length 70mm (2.7in), Height 30mm (1.2in) On Nov-26-14 at 18:12:15 PST, seller added the following information:
