Stereo Encoder Module Pira

US $160

Beograd, default, Serbia
Nov 6th

Open on mobile:
QR code

from PIRA website: "This stereo encoder is a halfway between analogue and digital processing. It combines the best from both domains to provide high-quality and easy to build device. The sampling frequency used in this stereo encoder is 97 times (!!!) higher than the pilot tone frequency. This makes very easy to reject all spectral residues around the sampling frequency without affecting the main signal characteristics. Using of a microcontroller allows to build this stereo encoder with reduced part count and get excellent results in real operation." Characteristics: Signal overshooting prevention (overshooting max. 10 %) Low noise and distortion Pilot tone level, audio gain and output level adjustment High channel separation and spectral purity in common operation RDS input and pilot sync. output makes easy to connect any RDS encoder Microcomputer controlled Balanced audio input Supply voltage: 9-16 V (stabilized) Quiescent supply current (12 V): 34 mA Audio 19 kHz rejection: 40 dB Channel separation at 1 kHz: >55 dB Subcarrier rejection: >60 dB Pilot sampling frequency: 1.843 MHz (19 kHz x 97) Subcarrier sampling frequency: 1.843 MHz (38 kHz x 48.5) Pilot sync. output: TTL Max. audio input voltage: 10 V pp (3.55 V rms) Pilot tone level: linear adjustable 0-0.5 V pp Output voltage gain: linear adjustable 0-2.5 Audio input impedance: 600/10K ohm jumper selectable RDS input impedance: 1000 ohm MPX output impedance: 500 ohm Pilot sync. output impedance: 10000 ohm Signal-to-noise ratio: >70 dB Business Policy 1. Payment * PayPal only. * Payment must be made within 5 days of purchase. * Import duties, taxes and charges are not included in the item price or shipping charges. - These charges are the buyer's responsibility. 2. Shipping * Worldwide shipping is available. * We ship to Paypal's address only. Please make sure your address is correct before you pay. * Items will be shipped within 1-2 business day after receiving cleared payment. * Shipping usually takes between 15-30 days. - Normally item is arrived within 15 days most countries but can be delayed due to local custom and country. - It could take up to 40 days to be arrived in Russia and South America. - Shipping method will depend on the item's condition, size, and/or volume, usually shipped by airmail with tracking number. 3. Return Policy * Please contact us first for an exchange or refund within 7 days after the item was received. * No returns accepted if it is item for sale in “AS IS" condition. * Returns will only be accepted in original condition and packing with all components and accessories included. - Buyer is responsible for mailing postage of an exchange or refund. * For any damaged or defected item, an exchange or full refund will be issued through PayPal if you submit appropriate proof. * Item for an exchange or refund can be returned within 60 days of receipt. * Refund will be issued immediately after we receive the item back. * Guaranteed not DOA. 4. Customer Service * If you have any questions or problems, please feel free to contact us. * For customer's satisfaction, we will always do our best.
