Stereo Msgeq7 Breakout Board (7-band Graphic Equalizer) For Arduino, Rpi, Pic

US $17.95

  • Cupertino, California, United States
  • Jun 9th
Open on mobile:
QR code
You are buying a Stereo MSI MSGEQ7 Seven band graphic equalizer breakout board. This board has two MSGEQ7 IC's on it so the left and right audio channels can be analyzed separately. Here is the datasheet for the MSGEQ7: http://www.mix-sig.com/images/datasheets/MSGEQ7.pdf Sample application for Arduino can be found here: https://github.com/engineertype/MSGEQ7 Both the LEFT and RIGHT channels are fed into separate MSGEQ7 IC's. This allows you to analyze and act on each channel audio independently. Specifications: 2 x MSGEQ7 7-band graphic equalizer mounted on PCB with all supporting components 3.3V or 5V operation 6-pin 0.1" header 3.5mm stereo audio jack Two screw holes for mounting the board Dimensions: 1.3" x 1.0" (33mm x 27mm) Works with Arduino, Raspberry Pi, BeagleBone and other microcontrollers Included in this auction: Stereo MSGEQ7 7-band graphic equalizer breakout board as shown in photos The header and stereo socket come soldered to the board. If you want them NOT soldered then just leave a note with your purchase. The IC's were bought directly from MSI, and are RoHS compliant. Designed and manufactured in California. Bid with confidence - eBay member since 1999. 100% positive feedback! Click here to see my feedback for everything I've sold.
