STEVAL-IFP002V1 - High Side Driver - 8 Channel based on VN808, US $24.00 – Picture 0
STEVAL-IFP002V1 - High Side Driver - 8 Channel based on VN808, US $24.00 – Picture 1
STEVAL-IFP002V1 - High Side Driver - 8 Channel based on VN808, US $24.00 – Picture 0
STEVAL-IFP002V1 - High Side Driver - 8 Channel based on VN808, US $24.00 – Picture 1

Steval-ifp002v1 - High Side Driver - 8 Channel Based On Vn808

US $24.00

  • San Ysidro, California, United States
  • Jan 29th
Open on mobile:
QR code
In order to protect the high-side driver (HSD) from the harsh industrial conditions of power supply lines, usually optocouplers and Transil diodes are used to separate the application control circuits from the power supply. The VN808 reference design board uses multi-channel optocouplers suitable for surface-mounted assemblies that consist of a photo transistor optically coupled to a gallium-arsenide infrared emitting diode. The isolation voltage for this type of optocoupler is 2500 VRMS. The clamping function of Transil diodes protect the HSD against transient overvoltages. The reference design board is assembled with uni-directional Transil diodes because they protect the HSD against both positive and negative surge pulses. Key Features Application conforms to: IEC 61000-4-4 (4kV), IEC 61000-4-5 (2kV), IEC 61000-4-6 (10kV) 16 output channels up to 0.5A per channel 16 digital inputs & 2 digital output Decoupling power & microcontroller section by optocouplers DC/DC converteron boards Protection against Surge/Burst by ST Transils Operation temperature -25°C to 85°C Power supply up to 35V Very low stand-by current  More Information:  st.com/web/catalog/tools/FM116/SC1076/PF125349 Ask if you have any questions.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand STMicroelectronics
Model STEVAL-IFP002V1
