Stm32 Board Stm32f207vct6 Stm32f207 Cortex-m3 Arm Development Board Kit+5 Module

US $89.99

Shenzhen, Guangdong, China
Jan 29th

Open on mobile:
QR code

Note: Item has been updated, while the title is not allowed to change, if there are any differences between the title and the page detail description, the latter shall prevail. This auction is for Open207V-C Package A STM32 development board designed for STM32F207V series, features the STM32F207VCT6 MCU, and integrates various standard interfaces, pretty easy for peripheral expansions. Overview Open207V-C is an STM32 development board designed for the STM32F207VCT6 microcontroller, consists of the mother board and the MCU core board Core207V. The Open207V-C supports further expansion with various optional accessory boards for specific application. The modular and open design makes it the ideal for starting application development with STM32F4 series microcontrollers. What's on the mother board MCU core board connector: for easily connecting the Core207V ULPI interface: for connecting high-speed USB peripheral (the STM32F207V integrates USB HS controller without any PHY device) FSMC + SPI interface (16-bit FSMC + SPI): for connecting touch screen LCD FSMC interface (8-bit FSMC): easily connects to peripherals such as NandFlash, Ethernet, etc. SPI1/SPI2 + AD/DA interface easily connects to SPI peripherals such as DataFlash (AT45DBxx), SD card, MP3 module, etc. SPI1 features AD/DA alternative function, supports connecting AD/DA module as well SDIO interface: for connecting Micro SD module, features much faster access speed rather than SPI I2S2/I2S3/I2C1: for connecting I2S peripherals, such as Audio module USART2 interface: easily connects to RS232, RS485, USB TO 232, etc. CAN1 interface: communicates with accessory boards which feature the CAN device conveniently CAN2 interface: communicates with accessory boards which feature the CAN device conveniently I2C1/I2C2 interface: easily connects to I2C peripherals such as I/O expander (PCF8574), FRAM (FM24CLxx), etc. DCMI interface: for connecting digital camera UART3 interface: easily connects to RS232, USB TO 232, etc. Ethernet interface: easily connects the MCU to ethernet network by using an additional ethernet module ONE-WIRE interface: easily connects to ONE-WIRE devices (TO-92 package), such as temperature sensor (DS18B20), electronic registration number (DS2401), etc. 5V DC jack 5V/3.3 V power input/output: usually used as power output, also common-grounding with other user board MCU pins connector: VCC, GND, and all the I/O ports are accessible on expansion connectors for further expansion SD Card Detect jumper LEDs jumper short the jumper to connect to default I/Os used in example code open the jumper to connect to custom I/Os via jumper wires User key/Wake-Up button jumper short the jumper to connect to default I/Os used in example code open the jumper to connect to custom I/Os via jumper wires Joystick jumper short the jumper to connect to default I/Os used in example code open the jumper to connect to custom I/Os via jumper wires LCD backlight adjustment jumper short the jumper to enable LCD backlight adjustment open the jumper to disable and disconnect from the I/O ports LEDs: convenient for indicating I/O status and/or program running state User key: convenient for I/O input and/or interact with running code Wake-Up button: wake up the STM32 MCU from sleep mode, also used as regular user key Joystick: convenient for I/O input (five positions) What's on the Core207V STM32F207VCT6: the high performance STM32 MCU which features: Core: Cortex-M3 32-bit RISC Operating Frequency: 120MHz, 150 DMIPS/1.25 DMIPS/MHz Operating Voltage: 1.8V-3.6V Package: LQFP100 Memories: 256kB Flash, 128+4kB SRAM MCU communication Interfaces: 3 x SPI, 3 x USART, 2 x UART, 2 x I2S, 3 x I2C 1 x FSMC, 1 x SDIO, 2 x CAN 1 x USB 2.0 high-speed/full-speed device/host/OTG controller with dedicated DMA, ULPI and on-chip full-speed PHY 1 x 10/100 Ethernet MAC 1 x 8 to 12-bit parallel camera interface AD & DA converters: 3 x AD (12-bit, 1?s, shares 24 channels); 2 x DA (12-bit) Debugging/Programming: supports JTAG/SWD (serial wire debug) interfaces, supports IAP AMS1117-3.3 (on bottom side): 3.3V voltage regulator MIC2075 (on bottom side): onboard USB power management device Power supply switch, powered from 5Vin or USB connection Boot mode switch, for configuring BOOT0 pin Power indicator Reset button 8M crystal oscillator 32.768K crystal (on bottom side), for internal RTC with calibration JTAG/SWD interface: for debugging/programming USB connector, used for establishing USB communication between PC and the STM32 development board IO expander (including VCC/GND), all the MCU pins are accessible on expansion connectors for further expansion 5Vin pinheader, 5V power supply is required when using USB HOST/OTG USB jumper short the jumper to when using USB open the jumper to disconnect from I/O ports VBAT selection jumper short the jumper to use system power supply open the jumper to connect the VBAT to external power, such as battery VREF selection jumper short the jumper to connect VREF+/VREF- to VCC/GND open the jumper to connect VREF+/VREF- to other custom pin via jumper wire Photos Open207V-C development board Open207V-C development board Open207V-C development board back view Open207V-C mother board MCU core board Core207V MCU core board Core207V Connecting to a debugger Connecting to various peripherals Open207V-C ?C/OS-II (I) Open207V-C ?C/OS-II (II) Open207V-C ?C/OS-II (III) Open207V-C ?C/OS-II (IV) Connecting to USB device through OTG cable Connecting to USB3300 USB HS Board Connecting to UDA1380 Board Connecting to OV9655 Camera Board Connecting to RS232 Board Connecting to RS485 Board Connecting to USB UART Board Connecting to CAN Board Connecting to 8 Push Buttons Connecting to 5 IO Keypad Connecting to AD Keypad Test Board on the AD/DA port Connecting to FRAM Board Multi I2C peripheral Module connected to the I2C bus Connecting to DataFlash Board Connecting to VS1003B MP3 Board Connecting to NRF24L01 RF Board Connecting to Micro SD Storage Board Connecting to NandFlash Board Connecting to Ethernet Board Connecting to any accessory board you need Note: The Open207V-C supports programming via STM32 UART bootloader, a USB TO UART accessory board is also provided in the package. The Open207V-C does NOT integrate any debugging function, a debugger is required. JTAG/SWD interfaces The figure 1, and 2 show the header pinouts of JTAG/SWD interface Figure 1. JTAG Header Pinout Figure 2. SWD Header Pinout Development Resources The User Guide CD includes development resources listed as follow: Related software (KEIL etc.) Demo code (examples in C, ?C/OS-II) Schematic (PDF) STM32 development documentations (Datasheet etc.) Package Contains The "Standard Package" and "Accessory Boards Package" below are included. Standard Package Open207V-C development board x 1 PL2303 USB UART Board (mini) x 1 USB type A plug to mini-B plug cable x 1 USB type A receptacle to mini-B plug cable x 1 4-pin wire x 2 2-pin wire x 2 USB power cable x 1 User Guide CD x 1 1 2 3 4 5 6 7 8 Accessory Boards Package 3.2inch 320x240 Touch LCD (A) x 1 USB3300 USB HS Board (ULPI) x 1 DP83848 Ethernet Board (ETH) x 1 NandFlash Board (A) (FSMC) x 1 OV7670 Camera Board (DCMI) x 1 Ethernet Cable x 1 1 2 3 4 5 6 Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
Country/Region of Manufacture	China
Model	Open207V-C Package A
