Overview Ficus STM32F103 is a STM32 development board that features a STM32F103VCT6 device as the microcontroller. It supports further expansion with various optional accessory boards for specific application. The modular and open design makes it the ideal for starting application development with STM32 connectivity line microcontroller. What's On Board 1.STM32F103VCT6: - Core: ARM Cortex-M3 32-bit RISC - Operating Frequency: 72 MHz; 1.25 DMIPS/MHz - Operating Voltage: 2-3.6V - Package: LQFP100; - I/Os: 80 - Memories: 256kB Flash, 48kB RAM - Communication Interfaces: 3 x SPI, 5 x USART, 2 x I2S, 2 x I2C, 1 x SDIO, 1 x USB, 1 x CAN, 1 x FSMC(SRAM, PSRAM, NOR, NAND, LCD) - AD & DA converters: 3 x AD (12-bit, 1?s, shares 16 channels); 2 x DA (12-bit) - Debugging/Programming: supports JTAG/SWD (serial wire debug) interfaces, supports IAP 2.74LVC139: Extending the FSMC such as an SRAM, LCD, NAND FLASH 3.AMS1117-3.3: 3.3V voltage regulator 4.Power indicator 5.LEDs: Convenient for indicating I/O status or program debugging running state 6.Keys: 1 x Reset, 3 x User keys 7.8M crystal oscillator: enables the MCU run at 72M frequency by frequency multiplication 8.32.768K crystal, used for internal RTC, also supports clock calibration 9.JTAG/SWD interface: for debugging/programming 10.USB interface: used for establishing USB communication between PC and the STM32 development board 11.USART interface: supports ISP (In-System Programming) through USART as well as system signal output 12.SDIO interface: connected with Micro SD module / SDIO WIFI module 13.I/O(8-bit) interface: access the 4 * 4 keyboard module, motor module, custom modules, etc 14.SPI interface: access the SPI module such as SPI Flash module, SD card module, VS1003/1053 MP3 module, MMA7455L acceleration sensor module, ENC28J60 Ethernet module and other sensor module with SPI interface 15.I2C interface: access the I2C module such as I/O port expansion chip PCF8574, EEPROM 24C02 module, MPU6050 gyroscope module, AM2311 temperature and humidity measurement module, BH1750FVI light measurement module, BMP085 atmospheric pressure measuring modules 16.FSMC(8-bit) interface: access the NAND Flash modules 17.FSMC(16-bit+SPI) interface: access the LCD module with TFT touch screen 18.ONE-WIRE interface: access ONE - WIRE device (the TO - 92 encapsulation) such as temperature sensor DS18B20, the electronic registration code DS2401 module 19.IR interface: IR-send: the infrared sending module; IR-receive: the infrared receiving module 20.AD & DA interface: connect the sensor of analog output such as MQ series gas measurement sensor module, the infrared temperature measurement module, light intensity measurement module, etc 21.CAN interface: access CAN module 22.7-SEG digital tube interface: access seven segment digital tube module with decimal point four 23.LED dot matrix interface: access the 32 * 64 or greater LED dot matrix module to realize the control of LED dot matrix 24.IO expander: all the MCU pins are accessible on expansion connectors for further expansion 25.Power input/output header, 5V/3.3V, usually used for power output, or common ground with other user board 26.5V DC power jack 27.Boot mode selection: for configuring the BOOT0 and BOOT1 pins 28.Power supply switch: powered from 5V DC jack or USB connection 29.USB enable jumper - Short the jumper to enable the PC auto detection while USB connecting - Open the jumper to disable 30.VBAT selection jumper - Short the jumper to use system power supply - Open the jumper to connect the VBAT to external power such as battery 31.User LEDs jumper - Short the jumper to connect to I/Os used in example code - Open the jumper to connect to other custom pins via jumper wires 32.User keys jumper - Short the jumper to connect to I/Os used in example code - Open the jumper to connect to other custom pins via jumper wires 33.VREF selection jumper - Custom ADC input reference voltage Development Resources Ficus STM32F103 development board include development resources listed as below: - Examples in C - Schematic (PDF) - Development documentations What Is Included 1.Ficus STM32F103 development board x 1 2.PL2303 USB UART Board (mini) x 1 3.USB type A plug to mini-B plug cable x 1 4.3.2" TFT LCD Module Display + Touch Panel + PCB adapter x 1 5.RS232 To TTL Converter Module COM Serial Board x 1 6.TTL To RS485 Module x 1 7.ENC28J60 Ethernet LAN / Network Module x 1 8.AT24C02 I2C EEPROM memory module x 1 9.AT45DB04 SPI DataFlash Shield Module x 1 10.SN65HVD230 CAN Board Transceiver Evaluation Development Module x 1 11.Micro SD Card Module Slot Socket Reader x 1 Detail please look at website: www.viewtool.com Posted with eBay Mobile
