Storm32 Nt Imu

US $760

  • Klaipeda, Lithuania
  • Jun 10th
Specifications: - Input voltage: 2 - 5.5 V. - StorM32 version: 2.03-NT and higher. - Dimensions: 17mm x 24mm x 2.1mm. LED Status: - 1 Hz blink - OK, bottom IMU setting. - 0.5 Hz blink - OK, top IMU setting. - 5 Hz fast blink - Error status. The controller is unable communicate with MPU6050 chip. Top/Bottom IMU settings: Module works as bottom (camera) IMU by default, to set it as TOP IMU, solder bridge (showed in photo) should be shorted. If you require to get TOP IMU, write message while ordering, we will short it. Important note: Version 1.0 module has an error on the back silkscreen print which says "VCC RX TX GND" it should be reversed "GND RX TX VCC" Firmware Updated and Info: Storm32-NT-IMU Flashing: Instructions will be provided on the GitHub page. Package: - StorM32 NT IMU CHIP with newest firmware. - No additional wires.
