Stridsberg Engineering Mca208m Vhf Uhf Receiver Multicoupler Antenna Cables Dc

US $800

Saint Louis, Missouri, United States
Jun 15th

Open on mobile:
QR code

This is a like new working unit. It was used sparingly. You will receive the working unit, the DC power cord, and 7 antenna cords of varying lengths! Free Fast FedEx Shipping! MCA208M is an active multicoupler designed to distribute VHF/UHF antenna signals to eight (8) receivers without loss and with high isolation between ports. It is specifically suited for signal intercept and VHF/UHF monitoring stations, both fixed or mobile platforms. It can be used in any monitoring post using receivers, scanners or spectrum analyzers. MCA208M has a mechanical and electrical design construction that will meet any government, military or commercial specification. This unit is designed to give high performance results in any radio monitoring post using multiple intercept receivers. Rugged die-cast aluminum enclosure with a black powder coat finish is standard, olive drab green (MIl-841OD) is also available on request. Frequency Range: 25 MHz to 1 GHz. 8-Ports Nominal Impedance: 50 ohm Port-To-Port isolation (min): 22 dB Return Loss (all ports): > 20 dB P1dB = 17 dBm (output) 3OIP = 32 dBm (output Coupler Gain/Loss: +2 dB to -1 dB (max) over frequency range RF Connectors: BNC (standard) Mechanical: 4.75 X 3.75 X 1.50 inches (L.W.H) Case: Die cast Aluminum, Black powder coating (standard) DC Power Connector: 2.1/5.5mm coaxial (standard) DC Power Requirements: +12VDC (nominal) @ 85 mA
