STV9379 Vertical Deflection Booster (Lot of 5 pieces), US $39.95 – Picture 0

STV9379 Vertical Deflection Booster (Lot of 5 pieces), US $39.95 – Picture 1

STV9379 Vertical Deflection Booster (Lot of 5 pieces), US $39.95 – Picture 2

Stv9379 Vertical Deflection Booster (lot Of 5 Pieces)

US $39.95

Las Vegas, Nevada, United States
Apr 26th

Open on mobile:
QR code

POWER AMPLIFIER FLYBACK GENERATOR THERMAL PROTECTION OUTPUT CURRENT TO 2.0APP FLYBACK VOLTAGE TO 90V (on Pin 5) SUITABLE FOR DC COUPLING APPLICATION DESCRIPTION Designed for monitors and high performance TVs, the STV9379 vertical deflection booster delivers flyback voltages close 90V. TheSTV9379 operates with supplies up to 42Vand provides to 2APP output current to drive the yoke. The STV9379 is offered in HEPTAWATT package. PIN CONNECTIONS Non-inverting Input Output Stage Supply Output GND Flyback Generator Supply Voltage Inverting Input Parameter Supply Voltage (Pin 2) (see note 1) Flyback Peak Voltage (Pin 6) (see note 1) Amplifier Input Voltage (Pins 1-7) (see note 1) Maximum Output Peak Current (see notes 2 and 3) Maximum Sink Current (first part of flyback) < 1ms) Maximum Source Current < 1ms) ESD susceptibility : EIAJ Norm (200pF discharged through 0) Operating Ambient Temperature Storage Temperature Junction Temperature Versus Pin 4. The output current can reach 4A peak for t 10µs (up to 120Hz). Provided SOAR is respected (see Figures 1 and 2). Symbol R th (j-c) Tt Tjr Parameter Junction-case Thermal Resistance Temperature for Thermal Shutdown Hysteresis on Tt Recommended Max. Junction Temperature Max. Value Unit Symbol I1 I7 VIO VIO/dt V3L V3SH Parameter Operating Supply Voltage Range Pin 2 Quiescent Current Pin 6 Quiescent Current Max. Peak Output Current Amplifier Bias Current Amplifier Bias Current Offset Voltage Offset Drift versus Temperature Voltage Gain Output Saturation Voltage to GND (Pin 4) Output Saturation Voltage to Supply (Pin 6) Diode Forward Voltage between Pins 5-6 Diode Forward Voltage between Pins 3-2 Saturation Voltage on Pin 3 Saturation Voltage to Pin 2 (2nd part of flyback) = 25V Test Conditions Versus Pin 0 5 Min. 10 Typ. Max. Unit µA mV µV/oC dB
