New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Gallery Wholesales Power Modules Sensor Modules Wireless Modules Function Modules DIY Modules LCD Modules Development boards Digital Voltmeters Description High-power ASK Transmitter Module STX882 1. Description STX882 is a low cost, small size, ultra-high-power, low harmonic ASK transmitter module. Has high stability and high cost, at 3.6V power to achieve 50mW, is currently on the market under the same voltage transmit power ASK transmitter module. The module can be connected to the microcontroller directly. So it is more convenient for user developing wireless products. 2. Features 2.1 Frequency Range: 433MHZ 2.2 ASK modulation mode 2.3 Small volume low self radiation 2.4 High-power long-range 2.5 Frequency stability 2.6 Various international testing standards 3.Application 3.1 Remote door 3.2 Wireless security alarm 3.3 Wireless industrial control 3.4 Wireless data transmission 4.Electrical Specifications: Parameter Min. Typ. Max Unit Conditions Operation conditions Supply Voltage 1.2 3.0 6 V Operating Temperature Range -20 25 70 ? Current consumption TX current 34 mA @3.3V,15dBm Sleep Current ?0.01 uA @DATA As Low level RF parameters Frequency Range 433.82 433.92 434.02 MHZ @433MHZ 314.9 315 315.1 MHZ @315MHZ RF power 12 13 13.5 dBm @2.4V 14 15 15.5 dBm @3V 19.5 20 20.5 dBm @5V Air rate 0.1 9.6 Kbps 5. Pinout: Photo 5 6. Mechanism dimensions Photo 6 SRX882 Low Consumption Strong Driving Force Super Heterodyne Receiver Module 1. Description SRX882 is a micro power strong driving force super heterodyne receiver module. It is can support our transmitter module STX882/STX888. It has high stability, anti-interference and high cost-effective, also has a powerful driving force, certified by ROHS, FCC, CE, The module can be connected to the microcontroller directly. So it is more convenient for user developing wireless products. 2. Features 1. Frequency Range: 433MHZ 2. ASK /OOK modulation mode 3. Super anti-power interference 4. Low-power sleep less than 1uA 5. Low self radiation 6. Small size 7. Frequency stability and reliability 8. Various international testing standards 3.Application 3.1 Remote door 3.2 Wireless security alarm 3.3 Wireless industrial control 3.4 Wireless data transmission 4.Electrical Specifications: Parameter Min TP Max Unit Condition Operation conditions Supply Voltage 2.4 5 5.5 V Operating Temperature Range -30 85 ? Latency 20 ms @315MHZ 9 ms @433@HZ Current consumption Consuming current 2.5 mA @315MHZ 2.8 mA @433MHZ ?2 uA @CS=1 Or vacant RF parameters Frequency Range 433.82 433.92 434.02 MHZ @433MHZ 314.9 315 315.1 MHZ @315MHZ Sensitivity -110 -107 dBm @1.2Kbps Air rate 0.1 9.6 kbps Receiver bandwidth 200 KHz 5. Pinout: Photo 7 Pin Number Pin Definitions Description 1 ANT Matching 50 ohm antenna 2 GND Connected to power ground 3 VCC Positive power supply 4 CS High level to enable the module, low level to enter sleep mode 5 DATA Data output pin 6 GND Connected to power ground 7 ANT Matching 50 ohm antenna 6. Mechanism dimensions Photo 8 Shippment Payment Return Policy Feedback About us 1)All items will be shipped to your paypal address .Please update your latest address when you check out,and please make sure to provide us with correct,precise and detailed shipping address. 2)Most of the items will be shipped via Hongkong Airmail/Singapore Airmail .To US customers,we will send the package via E-packet . 3)All items will be shipped in 24 Hours (excluding Sat,Sun & Holiday) after payment received and cleared. For the long-time holiday, we'll post the info on our store and reply you automatically via emails. 4)Tax:We will do our best to help you to clear the goods,and the tax depends on each country custom. 5)If you don't receive items over 30 business days,please make sure to contact us before leaving any neutral or negative feedbacks.We'll try our best to help you solve the problem. 6)The product in our store is free shipping. But the shipping method is different based on your order.If your order is more than $40 ,we will send the items to you with tracking number for free.If your order is less than $40,the registered mail fee is on your side. We could also deliver your item via EMS,DHL or Fedex based on your requirement. 1. We only accept Paypal payment if you buy on ebay. 2. Please make sure you notice the entire desciption and agree to the transaction before buying. 1) If for some reason you're not satisfied with our service or product quality, please contact us within 3 days after you get the package, you can return the products to us in 30 days and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2) Although we test each item and they are packed professionally, few item(less than 0.1%) might be damaged during the shipping. You are welcome to contact us within 3 days after you receive your package about replacement. 3) Repair Some items might be broken caused by improper use, we are always happy to offer any helpful repair service. Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees. 1.Feedback is important to all of us participating on the eBay community. We are always working hard for maintain high standards of excellence and strive for 100% customer satisfaction. So your POSITIVE FEEDBACK is very important.<> 2.Here is an illustration showing how to leave the positive feedback, please follow the following step. Thank you so much. And welcome back to our store again.<> Chip_Partner is a Well-Known Online Supplier specializes in all kinds of IC products and all Consumer Electronics and Intelligent life supplies, such as electronic devices and components, development modules, Power modules, consumptive materials, household items, outdoor products, fishing gear and so on. Chip Partners are on Ebay for almost 10 years, and has owned thousands of registered customers from all over the world. We offer world wide free shipping and have already shipped to more than 150 countries including United Sates, United Kingdom, Canada, Australia, France, Germany, Russia, Italy, New Zealand, Spain, Brazil, Japan, Singapore, Korean, etc. We are more wiling to be your Long-Term Supplier in this filed, as we have these advantage of others: 1.Lowest Pirce, High Quality 2.Best Customer Service 3.Technical Support 4.Mass Quote Sevice 5.Extra Service if you need other items not listed in our shop On May-27-16 at 00:53:49 PDT, seller added the following information: inkfrog terapeak inkFrog Analytics On Nov-18-16 at 14:43:07 PST, seller added the following information:
