Super Multi Function Capacitance Inductance Resistance Senior Logging Multimeter

US $399.99

shenzhen, China
Jan 29th

Open on mobile:
QR code

VICTOR 187/189 Multi Function Digital Multimeter View All Pictures: VICTOR 187/189 Logging of True-rms digital multimeter IntroductionCharacteristics Feture: Measurements AC voltage, DC voltage, AC current ,DC current, OHM, Frequency, Period, Pulse width,Capacitance, Beep, Diode, dBm, Thermocouple (TC), Thermal resistance (RTD), AC+ DC, AC + Hz measurement, Maximum, Minimum, Average measurement (MAX / MIN / AVG), The relative value measurement (REL_%) Measurements show that 55,000 words, the basic accuracy 0.02% (VICTOR 189) / 0.05% (VICTOR 187) Three measurement rate: FAST, SLOW, SMOOTH, the fastest refresh rate of simulation bar: 14 / sec Manual range or automatic range selection Measuring data show that hold functional (DIS_HOLD) and automatically hold functions(AUTO_HOLD) Peak measurements, 500us peak sampling capture, capable of capturing crest Pulse AC voltage and AC current are true rms measurement, AC voltage bandwidth 20Hz~30KHz(VICTOR 187),20Hz-100KHz(VICTOR 189), AC current bandwidth 20Hz-30KHz Option 1 ~ 2400 ? reference impedance measurement of decibels Low pass filter function normally by the RP-raising and the frequency of the electrical waveform measurement results Can be configured clamp to measure the large current The eight kinds of thermocouple measurement, the two kinds of heat resistance measurement, high-precision cold-automatic compensation, °C or °F temperature display Large-screen display and more data can be displayed at the same time that is measurements and other information related to the measurement Built-in real-time clock, for the record and provide accurate measurement of time Easy to operate multi-parameter data record: manual records and records of the incident, and easy to query the data records Adopted panel calibration technology, can be done without opening the case calibration Use alkaline batteries, Ni-Hi battery-powered, the battery and fuse can be easily replaced. Backlight is automatically closed and automatic power off function Large-screen LCD display, with white LED backlighting The meter can communicate with computer by isolation interface USB Through the friendly interface, users can easily access the data of instrument in a number of parameters, and may be the data storage, processing, management, access to the data tables and other graphics or display Simple man-machine operating, delicate, strongly and suitable for field use Specifications for products Measurements Range Resolution Notifier DCV 5.0000V 0.0001V Input impedance: 10M? 50.000V 0.001V 500.00V 0.01V 1000.0V 0.1V DCmV 50.000mV 0.001mV Input impedance: approx. 100M? 500.00mV 0.01mV 2200.0mV 0.1mV ACV 5.0000V 0.0001V Input impedance: 10M? / 50pF CF
