Swagelok Quick-connect 1/2" Npt 316 Ss Qc8 Mating Pair Stainless

US $88

Toms River, New Jersey, United States
Jun 7th

Open on mobile:
QR code

You are bidding on a mating pair of swagelok QC8 series quick connect couplings Features Redesigned stem insert requires just one O-ring seal, yet improves O-ring containment. New-design stems and bodies interchange with old-design stems and bodies. Locking dog mechanism with large contact area retains stem. Push-to-connect coupling enables quick, easy operation. Wide variety of options, including keyed quick-connects, are available. Heavy-duty sleeve shields open end of body. Double-End Shutoff (DESO)—Red Stem Sleeve Body Material 316 Stainless Steel Connection 1 Size 1/2 in. Connection 1 Type Male NPT Bulkhead No Bulkhead Cleaning Process Standard Cleaning and Packaging (SC-10) Configuration Body Flow Coefficient 1.3 - If coupled with a DESO stem, 2.0 - If coupled with a SESO stem Size 1/2 in. UNSPSC (SWG01) 31163101 Air Inclusion 3 cm3 Body Valve Option Standard Body Valve Lubricant Dow Corning 111 O-Ring Fluorocarbon FKM Paint No Choice For Paint Pressure Rating Coupled at Max Temp 250 PSIG @ 400 °F /17.2 BAR @ 204 °C Pressure Rating Coupled at Room Temp 750 PSIG @ 70 °F /51.6 BAR @ 21 °C Pressure Rating UnCoupled at Room Temp 250 PSIG @ 70 °F /17.2 BAR @ 21 °C Pressure/Temp_ Rating (Coupling and Uncoupling) 250 PSIG @ 70 °F /17.2 BAR @ 21 °C Series Instrumentation Quick-Connect Sleeve Standard Sleeve Spillage 3 cm3 Spring Standard Spring Testing 3 cm3 eClass (4.1) 37110302 eClass (5.1.4) 37110302 eClass (6.0) 37-02-05-00 eClass (6.1) 37-02-05-00 UNSPSC (10.0) 27121701 UNSPSC (11.0501) 27121701 UNSPSC (13.0601) 27121701 UNSPSC (15.1) 27121701 UNSPSC (4.03) 31163101 Body Material 316 Stainless Steel Connection 1 Size 1/2 in. Connection 1 Type Male NPT Bulkhead No Bulkhead Cleaning Process Standard Cleaning and Packaging (SC-10) Configuration DESO Stem Flow Coefficient 1.3 - If coupled with a standard or reverse flow body Size 1/2 in. UNSPSC (SWG01) 31163101 Lubricant Dow Corning 111 O-Ring Fluorocarbon FKM Paint Painted red DESO sleeve Pressure Rating Coupled at Max Temp 250 PSIG @ 400 °F /17.2 BAR @ 204 °C Pressure Rating Coupled at Room Temp 750 PSIG @ 70 °F /51.6 BAR @ 21 °C Pressure Rating UnCoupled at Room Temp 250 PSIG @ 70 °F /17.2 BAR @ 21 °C Pressure/Temp_ Rating (Coupling and Uncoupling) 250 PSIG @ 70 °F /17.2 BAR @ 21 °C Series Instrumentation Quick-Connect Sleeve Standard Sleeve Spring Standard Spring eClass (4.1) 37110302 eClass (5.1.4) 37110302 eClass (6.0) 37-02-05-00 eClass (6.1) 37-02-05-00 UNSPSC (10.0) 27121701 UNSPSC (11.0501) 27121701 UNSPSC (13.0601) 27121701 UNSPSC (15.1) 27121701 UNSPSC (4.03) 31163101
