Sweep/signal Generator, 275 To 1050 Mhz, 1.5 +/- 4.5 Dbm

US $154.95

  • Albuquerque, New Mexico, United States
  • Jan 29th
Open on mobile:
QR code
  Shown in Images 1 through 6 is a Sweep/Signal Generator Assembly producing 1.5 +/-4.5 dBm output at frequencies from 275 to 1050 MHz on the front panel SMA connector.  Click on this URL, http://www.azdtechnology.com/ga10c.htm, for additional technical information.     For CW and swept frequency applications, the front panel dial is used to set the center frequency (CF).  To generate a swept frequency (Delta F), connection of a triangle waveform from a function generator to the Sweep/Signal Generator back panel BNC connector is required.  Image 4 shows holes in the chassis bottom that allow access to two 2-pin headers.  Installation or removal of a short is required on each header to change frequency bands and produce the Stand-By (SB) mode.     The Sweep/Signal Generator Assembly is supplied with a 36-inch length power cable permanently attached for connection to a DC power supply.  See Image 7 for details.  Image 2 shows the location on the chassis back panel of the DC power connections.  +18 VDC (Green) and -18 VDC (Yellow) connect to the chassis back panel feed-thru terminals, and common ground (black) is connected to a solder lug located on the lower center of the chassis back panel.      For information on Domestic and International shipping, see Images 8 and 9   This is a Category 1 Item   >>> PURCHASING MORE THAN 1 ITEM <<< For a sizeable reduction in Postage/Handling Cost, fill your shopping cart and wait 1 day or less for an invoice.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
MPN GA10C
Manufacturer AZD TECHNOLOGY
