Syk-8b 8t Hydraulic Knockout Punch Tool Stainless Steel Hole Opener Kit

US $94.99

Ellijay, Georgia, United States
Jul 22nd

Open on mobile:
QR code

SYK-8B 8T Hydraulic Knockout Punch Tool Stainless Steel Hole Opener Kit image is actual item sold Shipping Weight 21.5#. Can't free ship this beast! A'zon overstock item. Brand new never used. misterbbq thanks you for your business! Specification: Output: 8T Model: SYK-8B Weight about: 24 lb - 11 kg Working stroke: 0.87 inch - (22 mm) Package size: 16.1 X 9.5 X 5.1 inch - (41 X 24 X 13 cm) 6 x Dies & Punches : 0.87in, 1.08in, 1.34in, 1.69in, 1.93in, 2.36in - ( 22mm, 27.5mm, 34mm, 43mm, 49mm, 60mm) Opening Range: Stainless Steel Pate 1.6 mm - 1/16 inch Iron Plate 3 mm - 1/8 inch Note: 1. The hole opener can only open holes in the metal plate. The metal plate refers to the iron plate/aluminum plate below 4mm, and the stainless steel plate can only be within 1.2mm. 2. The hole opener tool is too sharp, please use it carefully to avoid injury 3. The size of the white gaskets in the seal, are all oblique cut, not a quality problem, not broken, not bad. (The spacer cannot be used without cutting and cannot be put into it. Therefore, for the convenience of everyone, we cut it one by one. If there is any missing cut, you can cut it diagonally with a box cutter.) Package includes 1 x 8 Ton Pump 1 x Ram with Hose 6 x Dies & Punches 1 x Big rod 1 x Pull rod 1 x Nut 1 x spacer 9 x Black and white seal ring 1 x Manual 1 x Sturdy Metal Carrying Case Steps for usage: 1. Before the hole is opened, the drill hole is first drilled with a 11.5mm guide hole. 2. Screw the piston rod into the screw hole of the piston cylinder, then insert the washer into the piston rod and insert it into the die. Then the piston rod is inserted into the guiding hole of the workpiece, and finally the blade edge of the punch is tightly combined with the processing surface, and the punch, the workpiece and the die are reliably fixed. 3. Close the oil return valve clockwise, then press and hold the force-applying handle repeatedly to start the piston pump. The oil pressure rises and the shearing knife increases between the concave and convex molds. The mold cuts the hole on the workpiece until it is cut. . Stop pressing the force-applying handle immediately after cutting 4. Loosen the oil return valve counterclockwise to completely unload the oil pressure. After the above four steps, complete a complete drilling operation procedure. 5, unscrew the punch, remove the waste plate in the die, wipe the mold Note: The hole opener can only open holes in the metal plate. The metal plate refers to the iron plate/aluminum plate below 4mm, and the stainless steel plate can only be within 1.2mm.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	UPC	Does not apply
Suitable Stainless Steel Thickness	0.06 in (1.6mm)
Model	SYK-8B Hole Punch Tool
6 x Dies & Punches	0.87in, 1.08in, 1.34in, 1.69in, 1.93in, 2.36in
Country/Region of Manufacture	China
Package weight	21.45 Ib (9.73kg)
Custom Bundle	Yes
Package length	16.14 in (41cm)
Material	Stainless Steel
Packaging wide	9.45 in (24cm)
Type	8 Ton 6 Die Hydraulic Punch
Package height	5.12 in (13cm)
Stroke	0.87 inch - (22 mm)
MPN	167094-enter
Suitable Steel Plate Thickness	0.12 in (3mm)
Brand	enter
