System 3r Mini Compatible 4 Position 20mm Edm Electrode Holder Cnc Gang Fixture

US $3,850.00

  • Milwaukee, Wisconsin, United States
  • Jan 30th
Open on mobile:
QR code
System 3R Mini Compatible 4 Position 20mm EDM Electrode Holder CNC Gang Fixture This is a very well made, what I am assuming to be, custom built fixture. It is non-hydraulic. Shanks are secured with a set screw and index snugly between dual mounted System 3R cam pins to allow for precise calibration, if needed. I indicated the surface of a system 3R check rule in each of the different locations. They seemed to all be off slightly by the same amount as if they were previously squared up individually after the unit was mounted to a machine. Allen wrench and 3R shank shown are not included. Weight: 23 Pounds / 10.4 Kilograms All reasonable offers considered. As is as shown. __________________________________________________________________________   Custom Steel Hand Stamp $65.00
