T3 Innovation Tla300 Tel Scope Telco Telephone Line Analyzer

US $256.45

Phoenix, Arizona, United States
Jan 29th

Open on mobile:
QR code

T3 Innovation TLA300 Tel Scope Telco Telephone Line Analyzer Features: Characteristics T3 Innovation TLA300 Tel Scope Telco Telephone Line Analyzer Physical Features Ergonomically designed body for most comfortable use 60 inch Angeled Bed of Nails with piercing clip cord set Listening speaker with fine volume adjustment Adjustable earpiece volume, hearing aid compatible Noise cancelling microphone Microphone mute with toggle on/off locking feature Soft key menu system simplifies user interface and customization Optional cushion boot for extra protection in ultra harsh environments Large LCD screen with On/Off option to conserve battery life Rainproof and highly water/dust resistant case to IP54 Standard Digital Protection Features Data Defender™ Data line-in-use capability (Data Defender is a trademark of Independent Technologies) High line voltage detection with next step options Active monitor circuitry minimizes load on subscriber line DTMF digit detection and display in monitor mode Detects DSL and T1 lines DigitView™, DTMF decode sees defects on customer equipment while dialing out PwrSave™ circuitry for Extra Long battery life Function FeaturesDisplayed on Lighted LCD Off-hook current and polarity On-hook voltage and polarity Ring amplitude and frequency On-hook and call waiting Caller ID info Amplified Line Monitor for volume levels comparable to “off hook” operation 8 number Stored memory with Alpha/Numeric tags Fuel Gauge Battery condition Continuous Polarity Indication Caller ID/Call Waiting Caller ID error detection Last Number redial - 24 digits Tone and Pulse dialing Configurable Auto Off in all modes Last number dialed, redialed or received Detection of T1 and DSL Lines Specifications T3 Innovation TLA300 Tel Scope Telco Telephone Line Analyzer Product Dimensions 8.25" x 2.5" x 2.0" without belt clip and cord set Product Weight 1lbs. 2oz Interface Attached cord set Languages English, Spanish and French Ringer Equivalence In BELL mode: 0.0 (no ringer load) Pulse Dialing Pulse rate: 10 pps ± 10%; Make/break ratio: 60% to 40% ±2%; USA Interdigit interval: 820 ms; Resistance during break: 120K Ohms minimum Tone Dialing DTMF output (into 600 Ohms): Tone-frequency error: ±1.5%; Tone Level: High group: -6 ±2 dBm; Low group: -8 ±2 dBm; High group vs. Low group Difference (twist): 2 ±1 dBm Flash Duration 600 ±50 ms Pause Duration Tone: 3 seconds; Pulse: 3.4 seconds Memory 8 programmable locations, 32 digits with 12 character tag, stored in non-volatile memory. Last number redial plus list of last 10 numbers dialed Return Loss Minimum 14 dB at 600 Ohms Line-Current Range 10 to 110 mA Apparent Line Resistance 275 Ohms at 20 mA Monitor Mode Impedance DC: 1MΩ typical AC: 390 KΩ at 1 KHz typical Measurement Voltage: 0 to 200 VDC ±5%; Current: 10 to 110 mA ±5%; NOTE: Do not attach test set to electric-power lines User Controls (1) Left-side-mounted TALK/BELL/MON push button switches for operating modes; (1) Right-side-mounted microphone mute pushbutton; (4) Front-mounted pushbuttons for various options; (1) Standard front-mounted 12-key phone keypad Display Transflective 128 by 64 pixel graphical liquid crystal display (LCD) with LED backlight Power 4 x AAA alkaline batteries Battery Life With 100% backlight and in speaker mode - 20 hours Backlight off and speaker off - 75 hours Standby - 2 years eBay Sales – Terms and Conditions Product Condition: All listed products are brand new, and come in the original packaging with a complete manufacturer’s warranty. Warranty: All Brand New products are covered by the Manufacturer’s Standard Warranty. The Standard Warranty usually applies to a one-year period, although some products come with a longer warranty. Please consult our Customer Care for more information. Payment Terms: PayPal is the main payment method. We also accept all major credit cards (Visa, MasterCard, American Express and Discover) for orders shipped within US. International customers are encouraged to pay via bank wire transfer. If you have questions regarding payment methods, quotes or any other matter related to sales, please contact our Customer Care department. Value Testers charges 8.3% sales tax for all shipments to Arizona addresses. Shipping: We only ship to addresses verifiable by either PayPal or credit card issuing bank. Please note that we cannot alter the address once a purchase is made. In the case of PayPal payment, we will ship orders when the payment is marked “Eligible” for PayPal Seller’s protection. Orders normally ship within 1 to 2 business days, if placed before noon MST. Tracking numbers are provided automatically. We do inspect products before a shipment is made, and all shipments are insured. In case of international shipments, clients are responsible for any duties, import taxes and brokerage fees. Shipments to Alaska and Hawaii may carry higher rates. Please contact our Customer Care department for the detailed information on shipping to Alaska and Hawaii. Returns: Before returning product, please contact our Customer Care to receive RMA (return material authorization number). Returns without RMA will not be processed. Returns of non-defective items are subject to 15% restocking fee, if returned 14 days past the delivery date. The customer is responsible for the shipping charges of the returned products. All products must be returned in their original and undamaged manufacturer’s packaging with all accessories and product manual. Return may be voided, if product is returned damaged or marked, or if any accessories or parts are missing. Please make sure to insure the return shipment, as UPS only automatically insures shipments up to $100 value. Our Customer Care can answer your questions Monday – Friday, between 7:00AM and 5:00PM MST.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	T3 Innovation
MPN	TLA300
Model	TLA300
