Taco 0012-f4-1 Circulator W/ 2" Flanges

US $285.00

  • United States
  • Mar 27th
Brand new in unopened box This model comes with 2" flanges Specs Material: Cast Iron Amperage: ? 1.33 Application: Heating Voltage: ? 115v Max Pressure (PSI): 125 psi Type: Pump Horse Power: ? 1/8 Connection Size: 1-1/2" Max Flow (GPM): 50 Flow Range (GPM): 0-50 Max Head (Ft): 14.5 Head Range (ft.): 0-14.5 Hertz: 60 Phase: 1 RPM: 3250 Temperature Range (F): 40° to 230°F Connection Type: Flanged Warranty: 3-Year Warranty Description for Taco 0012-F4 Note: Full flange-to-flange three-year warranty on all 00 Series circulators. Performance Data Flow Range: 0-50 GPM Head Range: 0-14.5 Feet Minimum Fluid Temperature: 40 degrees F (4 degrees C) Maximum Fluid Temperature: 230 degrees F (110 degrees C) Maximum Working Pressure: 125 PSI Connection Sizes: 1-1/4", 1-1/2", 2" Flanged The High Velocity Series Taco 0012 Cartridge Circulator is specifically designed for high-flow/medium-head applications in large residential/light commercial systems. Exclusive, Anti Condensate Baffle (ACB) protects motor windings on chilled water jobs. Available in cast iron or bronze construction. Bronze can be used on open-loop systems. Unique, replaceable cartridge contains all of the moving parts so you can service it easily instead of replacing the entire unit. Universal flange-to-flange dimensions and orientation allow the 0012 to easily replace other models. 0012-F4 is a direct replacement for the HV Series and the 0012-F4-1 is a direct replacement for the 2" Series using existing flanges. Features Exclusive Anti-Condensate Baffle (ACB) with Ambient Air Flow-Protects motor windings against condensate buildup High Velocity Performance Compact Design Quiet, Efficient Operation Unique Replaceable Cartridge Design-Field Serviceable Direct Drive-Low Power Consumption Self-Lubricating No Mechanical Seal Unmatched Reliability --Maintenance Free Universal Flange-to-Flange Dimensions Cast Iron or Bronze Construction Packed with 2" Flanges Typical Applications Large BTUH Boilers 2" Recirculation Loops Primary/Secondary Loops Commercial Water Heaters Light Commercial Heating and Cooling Systems Replacement Parts List: Casing O-Ring: 0012-006RP Flange Gasket Set: 0012-020RP Capacitor or PC Board: 009-018RP Cartridge Assembly Complete: 0012-011RP
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand TACO
Model 0012-F4-1
