Taperline, Tln-40, Locking Nut, New Old Stock

US $18000

Warren, Michigan, United States
Jun 13th

Open on mobile:
QR code

Taperline, TLN-40, Locking Nut, New Old Stock You are purchasing 1pc of #TLN-40 Face Lock Style Inch Bearing Locknuts Part No. TLN A DIA. B C DIA. D SLOT/ HOLE E F G PITCH DIA. H PITCH J PILOT DIA. K Face Lock Screw Sz Face Lock Min Torque Value Ft. Lbs Screw Size Min Torque Value Ft. Lbs *00 .875 .312 .625 .125 Diameter .120 .391 .3707/.3733 32 - - 10 2-3 *01 1.000 .312 .719 .125 .094 .469 .4487/.4513 32 - - 10 2-3 *02 1.125 .343 .813 .125 .094 .586 .5657/.5687 32 .5908/.5912 .156 10 2-3 03 1.125 .343 .938 .125 .094 .664 .6437/.6467 32 .6695/.6699 .156 10 2-3 10 2-3 04 1.375 .375 1.125 .188 .094 .781 .7607/.7641 32 .7876/.7880 .156 10 2-3 10 2-3 05 1.562 .406 1.281 .188 .094 .969 .9487/.9521 32 .9845/.9849 .156 10 2-3 10 2-3 06 1.750 .406 1.500 .188 .094 1.173 1.1369/1.1409 18 1.1813/1.1817 .156 10 2-3 10 2-3 065 2.062 .438 1.813 .188 .094 1.312 1.2764/1.2804 18 1.3145/1.3150 .156 10 2-3 1/4 4-6 07 2.062 .438 1.813 .188 .094 1.376 1.3399/1.3439 18 1.3783/1.3788 .156 1/4 3-4 1/4 4-6 08 2.250 .438 2.000 .250 .094 1.563 1.5269/1.5314 18 1.5751/1.5756 .156 1/4 3-4 1/4 4-6 09 2.531 .438 2.281 .250 .094 1.767 1.7309/1.7354 18 1.7720/1.7725 .156 1/16 N.P.T. 4-5 1/4 4-6 10 2.688 .500 2.438 .250 .094 1.967 1.9309/1.9354 18 1.9688/1.9693 .188 1/16 N.P.T. 4-5 1/4 4-6 11 2.968 .500 2.656 .250 .125 2.157 2.1209/2.1260 18 2.1657/2.1662 .188 1/16 N.P.T. 4-5 1/4 4-6 12 3.156 .531 2.844 .250 .125 2.360 2.3239/2.3290 18 2.3625/2.3630 .188 1/16 N.P.T. 4-5 1/4 4-6 13 3.375 .562 3.062 .250 .125 2.548 2.5119/2.5170 18 2.5594/2.5599 .188 1/16 N.P.T. 4-5 1/4 4-6 14 3.625 .562 3.312 .250 .125 2.751 2.7149/2.7200 18 2.7562/2.7567 .219 1/16 N.P.T. 4-5 1/4 4-6 15 3.875 .594 3.562 .375 .125 2.933 2.8789/2.8843 12 2.9531/2.9536 .250 1/16 N.P.T. 4-5 5/16 6-8 16 4.156 .594 3.844 .375 .125 3.137 3.0829/3.0888 12 3.1499/3.1504 .250 1/16 N.P.T. 4-5 5/16 6-8 17 4.406 .625 4.031 .375 .156 3.340 3.2859/3.2918 12 3.3469/3.3474 .281 1/16 N.P.T. 4-5 5/16 6-8 18 4.656 .688 4.281 .375 .156 3.527 3.4729/3.4803 12 3.5437/3.5442 .281 1/8 N.P.T. 9-10 5/16 6-8 19 4.938 .718 4.562 .375 .156 3.730 3.6759/3.6833 12 3.7406/3.7411 .313 1/8 N.P.T. 9-10 3/8 13-15 20 5.188 .750 4.812 .375 .156 3.918 3.8639/3.8713 12 3.9374/3.9379 .344 1/8 N.P.T. 9-10 3/8 13-15 21 5.438 .750 5.000 .500/.375 .188 4.122 4.0679/4.0762 12 4.1343/4.1349 .344 1/8 N.P.T. 9-10 3/8 13-15 22 5.718 .781 5.281 .500/.375 .188 4.325 4.2709/4.2792 12 4.3311/4.3317 .375 1/4 N.P.T. 16-18 3/8 13-15 24 6.125 .812 5.688 .500/.375 .188 4.716 4.6619/4.6702 12 4.7248/4.7254 .406 1/4 N.P.T. 16-18 3/8 13-15 26 6.750 .875 6.188 .625/.375 .250 5.106 5.0519/5.0602 12 5.1185/5.1191 .468 1/4 N.P.T. 16-18 3/8 13-15 28 7.094 .938 6.531 .625/.375 .250 5.497 5.4429/5.4512 12 5.5122/5.5128 .500 1/4 N.P.T. 16-18 3/8 13-15 30 7.688 .968 7.062 .625/.375 .281 5.888 5.8339/5.8422 12 5.9059/5.9065 .500 1/4 N.P.T. 16-18 3/8 13-15 32 8.062 1.031 7.438 .625/.375 .281 6.284 6.2028/6.2119 8 6.2996/6.3002 .531 3/8 N.P.T. 30-36 3/8 13-15 34 8.656 1.062 8.031 .625/.375 .281 6.659 6.5778/6.5869 8 6.6933/6.6939 .562 3/8 N.P.T. 30-36 3/8 13-15 36 9.062 1.094 8.375 .750/.375 .312 7.066 6.9848/6.9939 8 7.0870/7.0876 .562 3/8 N.P.T. 30-36 3/8 13-15 38 9.468 1.125 8.781 .750/.375 .312 7.472 7.3908/7.3999 8 7.4807/7.4813 .562 3/8 N.P.T. 30-36 3/8 13-15 40 9.844 1.188 9.156 .750/.375 .312 7.847 7.7658/7.7772 8 7.8744/7.8750 .625 3/8 N.P.T. 30-36 3/8 13-15 44 11.000 1.250 9.915 1.000/.375 .500 8.628 8.5468/8.5582 8 8.6618/8.6625 .688 3/8 N.P.T. 30-36 3/8 13-15 NOTE: All locking screws should be tightened equally to a maximum torque. Conditions may vary from the actual torque figures, however, listed values are minimums. All parts complete with locking screws. It is not necessary to use any type of locking fluid on the set screws. At no time should T A P E R L I N E (R) products be altered. The manufacturer shall not be held accountable for any product that has been altered. All items listed are low carbon steel. In the smaller thread sizes holding power of the face lock feature has its limitations. As thread size increases, holding power increases. T A P E R L I N E (R) recommends the use of the peripheral lock feature when applicable in the smaller sizes. Check your application for your torque requirements. New Old Stock Please see the photos. Please see our other auctions. Please feel free to contact us with any questions.
