Tb6612fng Dual Motor Driver Carrier

US $5.00

Miami, Florida, United States
Feb 12th

Open on mobile:
QR code

This tiny board is an easy way to use Toshiba’s TB6612FNG dual motor driver, which can independently control two bidirectional DC motors or one bipolar stepper motor. A recommended motor voltage of 4.5 V to 13.5 V and peak current output of 3 A per channel (1 A continuous) make this a great motor driver for low-power motors. Features and specifications Dual-H-bridge motor driver: can drive two DC motors or one bipolar stepper motor Recommended motor voltage (VMOT): 4.5 V to 13.5 V (can operate down to 2.5 V with derated performance) Logic voltage (VCC): 2.7 V to 5.5 V Output current maximum: 3 A per channel Output current continuous: 1 A per channel (can be paralleled to deliver 2 A continuous) Maximum PWM frequency: 100 kHz Built-in thermal shutdown circuit Filtering capacitors on both supply lines Reverse-power protection on the motor supply Real-world power dissipation considerations The TB6612 motor driver used on the carrier board has a peak current rating of 3 A per channel. The peak ratings are for quick transients (e.g. when a motor is first turned on), and the continuous rating of 1 A is dependent on various conditions, such as the ambient temperature. The actual current you can deliver will depend on how well you can keep the motor driver cool. The carrier’s printed circuit board is designed to draw heat out of the motor driver chip, but performance can be improved by adding a heat sink. This product can get hot enough to burn you long before the chip overheats. Take care when handling this product and other components connected to it. Included hardware A 1x16-pin breakaway 0.1" male header strip is included with the TB6612FNG motor driver carrier. This strip can optionally be soldered to the carrier board so that it can be used with perfboards, solderless breadboards, or 0.1" female connectors. (The headers might ship as two 1x8 pieces or as a single 1x16 piece that can be broken in half.) Schematic diagram We offer the great products with guaranteed quality. Shipping Terms: Your order will be processed within 1 to 2 business days after receipt of cleared payment. Transit time varies on shipping option. We will automatically email you with tracking information as soon as we process your order, within 1 to 2 business days. We only ship to the verified PayPal address supplied to us by eBay/PayPal Payments: We Accept Payments Via PayPal Only Sales Conditions: 14 days in order to get your money back or item exchange, buyer pays return shipping Buyers Pay for Return Shipping Cost 20% restocking fee will apply on all new items that have been opened and returned (except defective) Do not return the item before contacting us. Any return must include a return authorization number provided for us. After you report any problem wait for our answer. Item must be returned within 3 days after RMA instructions has been provided
