Tc4422 Mosfet / Igbt 9 A Driver, Turns Fet Full On -:

US $110

Valley Stream, New York, United States
Jan 29th

Open on mobile:
QR code

TC4422 CAT Power Gate Driver for MOSFET / IGBT 9 A drive current, Turns FET full On Case: TO220 Lot Size: 1 units See other listings and lot sizes for this item See other drivers Gate driver for power MOSFETs + IGBTs Does one thing, and does it very well: Turn MOSFETs and IGBTs hard ON, to attain their lowest specified Rds(on). (good luck attaining it otherwise). Turns them ON FAST, and turns them OFF FAST. It will both source and sink current from MOSFET gates to provide fast switching. Supply of 4.5 to 18V, 2.0 Amp continuous output current. 9A peak charging current into capacitive loads. Takes a logic level as input ( 3 to 18V logic high state), and it switches high powers on output. Rise time: 180 ns into 47,000 pF capacitive load 30 ns into 4700pF capacitive load. Output impedance: 1.4 ohm Designed to reduce both conduction losses (by fully enhancing the channel), and switching losses (by reducing rise/fall times to their specified minimum) in all MOSFETS. Can be used to drive other loads: motors, transformers, horn speakers (very loud alarm), signal generators, anything that can handle square waves. Internally Schmitt-triggered logic states produce decisive switching even for slow rising signals. If you're driving MOSFETS any other way, you end up struggling with rise times and incomplete turn-on, and you're not achieving rated MOSFET performance. The TC4421 (inverting version of this part), is also available. Check our other auction listings for it, or contact us, if you need inverting driver. Datasheet I only ship to buyer's EBAY shipping address IMPORTANT: Buyer controls combining of order, by making a single payment for all items. Multiple payments void any shipping discounts. Can only combine BEFORE payment, never after. How to combine orders. If you have ANY time constraints, contact seller BEFORE buying or bidding, so we can BOTH come to an agreement. INTERNATIONAL shipments will NOT have online tracking , unless you use REGISTERED MAIL -- contact seller for invoice. INTERNATIONAL transit time can be 6-28 business days, and can be delayed by local Customs backlogs. If this is not acceptable, we cannot not enter into any trade. US shipments can take 5-7 business days - however the USPS does NOT guarantee these transit times, and can exceed them. eBay tracking info has 24-48 hrs update latency and can only guarantee a delivery scan -- interim scans may not occur. ALL items shipped to buyer's Registered eBay shipping address address, without exception. We can never take an address from email. Payment closes order. No changes are possible once paid. We have no expedited shipping service outside USA -- If urgent, please source locally. International : If you want seller to be responsible for package in transit , you must choose Registered mail - adds $13 to S&H - contact seller for invoice. supreme supremewidgets supremeauctiononlinesoftware.widgets.EbayGalleryZ.swf supremewidgets supremeauctiononlinesoftware.widgets.GalleryCat.swf supremewidgets supremeauctiononlinesoftware.widgets.FeedbackWidgetBasic.swf

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	OEM
Model	TC4422 CAT
MPN	TC4422 CAT
Country/Region of Manufacture	United States
