Tcxo 0.1ppm 16.9344mhz 25m High Precision Golden Active Crystal Oscillator Dip08

US $18.00

Foshan,Guangdong, China
Jul 20th

Open on mobile:
QR code

This auction is for 1 pcs TCXO 0.1ppm 16.9344MHz Ultra precision Golden Oscillator (picture 100M for sample only) Please select the frequency you need directly, same price. if you need other customs frequency ,just email me, thanks. NOTE: DIY electronic skill&experience required! (If you need datasheet or more questions, please email us.) We provide customs works for TCXO: (1) Frequency: Range from 32.768KHZ to 200MHZ example: 5MHz, 8MHz, 10.6445MHz, 16MHz, 22.5792MHz, 24MHz,24.576MHz, 25MHz, 49.1520MHz, 80MHz, 100MHz, 125MHz etc. (2) Wave output: TTL/CMOS by default, we can make sinewave output if request (3) Packge: DIP08 by default, (we can make DIP14) (4) with PLL by default, Pin 1 is NC by default, if need customs requirment such as Voltage control for Pin 1 or Enable/Disable function, or OCXO, please email, thanks Features: Wide frequency range Offer customs work Frequency Accuracy 0.1ppm Low phase noise, Low-jitter Golden plated Specification for TCXO: TCXO full name: Temperature Compensated Crystal Oscillator Power voltage for TCXO : +5.0V dc(± 5%) (+3.3Vdc also compatible) if you request to make 5V , or 3.3V, please email. Power current : 20mA (MAX) Waveform : TTL/CMOS Duty cycle : 40/60% Frequency stability Vs Temp : +/- 1ppm (-10 ~ +60 ) Phase noise : -130dBc/1KHz@10M Package : DIP08 (dimension 12.8 x 12.9 x 7.5mm) Frequency Accuracy: ±0.1ppm Max. Aging : +/- 2ppm/year jitter: 1ps max., Pin function : Pin 1 : NC Pin 4 : GND Pin 5 : Output Pin 8 : VDD(DC Power Supply) Application: Application on home audio for digital audio, DAC, Raspberry Pi3/ Pi4, CD player, CD turnable, Car audio CD player etc. We also provide suitable voltage regulate power supply module DIP socket for it. you can check my store, thanks

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Number of Pins	4
Termination Style	Pin
Type	Crystal Oscillator
Color	golden
Oscillator Frequency	16.9344 MHz
Compatible Brand	Universal
MPN	does not apply
Brand	JYEC
