Tda2030a Audio Power Amplifier Diy Kit Components Ocl 18w X 2 Btl 36w

US $810

Nanjing, Jiangsu, China
Jan 29th

Open on mobile:
QR code

Features Great PCB for Two kind of connections (OCL and BTL) Double kneading board design PCB Size:40mm X 92mm X 1.6mm Power Input:2 X 12VAC, that is 12V - 0 -12V AC Dual-channel kit can be accessed by OCL or mono BTL circuit, flexible, wide range of applications. The famous 1% metal film resistors in China, capacitors and film capacitors, two 3300uF/25V filter capacitors. Volume on the design board potentiometer.The circuit board design is reasonable, low noise, high performance-price ratio, is the beginner's first choice! NO 1: For OCT Type, R4 needn't to be connected. No 2: For BTL Type, C9 needn't to be connected and singnal is inputed from the right part of the RCA sockets. Package Include: PCB,Components,installation drawing. List Double-Sided PCB 1 1 Ohm metalfilmresistor 2 TDA2030A+Insulating Material 2 680 Ohm metalfilmresistor 2 3300U/25V 2 4A/600V Rectifier bridge 1 22u/50V 4 2 wire holder 2 2.2u/50V 2 3 wire holder 1 0.1u 2 Installation drawing 1 22K Metalfilmresistor 5 RCA sockets & Potentiometers 1 (what you will receive are just components and you need to assemble it by yourself) Thanks a lot for your attention! :) We aim to provide high quality products and a greater service to you and a five'' stars* rating from you for each and every transaction is welcome. Thanks a lot. :) If you are not 100% satisfied,PLEASE don't leave a neutral or negative but contact us First so that we can help you. Please feel free to contact us if you have any questions. :) Payment We accept payment by Paypal. Shipping We ship by Airmail. We will select the fast and reliable way for delivery. Save on shipping and safer on delivery. We are not responsible for wrong or undeliverable address. Tracking number: The price is USD2.00, it is optional but you are recommended to use it. Please contact us to buy if you need it. Delivery time By airmail: 2-4 weeks to ASIA, West EURO, and North America. 3-5 weeks to South America, Mid-East, East EURO and Africa. Over 45 days to Russia , Italy By EMS: 5-7 business days For more information about the shipping time and please refer to the following link: http://members.ebay.com/ws/eBayISAPI.dll?ViewUserPage&userid=skt_flyer For public holiday in China and the delivery time will be delayed for some days due to the post office and customs will have holiday and the process of the package will be delayed. International Buyer please note 1 We are not responsible for any custom duty or import tax.These charges are not included in the item price and shipping cost. 2 Please Check with your country's customs office to determine what these additional costs will be prior to bidding/ buying. Return If you are not satisfied when you receive your item, please return it within 7 days for a replacement or money back. Please contact me before you return it. Not accept returning of electronic components. Full refund after we receive our original item.
