Tda7560 / C1a00000021 Panasonic Oem Audio Power Ic For Cqc, Cqd Series Car St.

US $12.00

Downey, California, United States
Jan 29th

Open on mobile:
QR code

TDA7560 / C1A00000021 Panasonic OEM Audio Power IC for CQC, CQD Series Car St. Item: Panasonic OEM Audio Power IC. for CQC, CQD series Car Stereo & Others. For Reference Only Not Implied Guaranty. Make sure of Matching Part No. Compatible Models CATU7000U CQC1300U CQC3100U CQC3200U CQC3300U CQC3400U CQC5110U CQC5210U CQC5310U CQC5410U CQDF200U CQDF203UC QDF401U CQDF402U CQDF583U CQDF600U CQDF601U CQDF783U CQDF800U CQDF801U CQDFX400U CQDFX403U CQDFX501U CQDFX683U CQDFX700U CQDFX701U CQDVR7000U CQDVR909U CQFX620U CQSRX7000U Items is New ,opened for Pictures. Once Used ,No Return & No Refund. Panasonic C1EA00000021, TDA756D Ic Panasonic parts and accessories Part Number C1EA00000021 Description Ic Substitute Part n/a Estimated Weight 1.000 lb(s). Alias part numbers TDA756D Core Price 0.00 Part Price 61.17 Total Price 61.17 Specs. TDA7560 4 x 51 W quad bridge car radio amplifier ? Superior output power capability: –4 x 51 W/4 max. –4 x 45 W/4 EIAJ –4 x 30 W/4 @ 14.4 V, 1 kHz, 10 % –4 x 80 W/2 max. –4 x 77 W/2 EIAJ –4 x 55 W/2 Multipower BCD technology MOSFET output power stage Hi-Fi class distortion Low output noise Standby function Mute function Automute at min. supply voltage detection Low external component count: – Internally fixed gain (26 dB) – No external compensation – No bootstrap capacitors On board 0.35 A high side driver Protections: – Output short circuit to GND, to V, across the load – Very inductive loads – Overrating chip temperature with soft thermal limiter – Output DC offset detection – Load dump voltage – Fortuitous open GND – Reversed battery – ESD Description The TDA7560 is a breakthrough BCD (Bipolar / CMOS / DMOS) technology class AB audio power amplifier in Flexiwatt 25 package designed for high power car radio. The fully complementary P-Channel/N-Channel output structure allows a rail to rail output voltage swing which, combined with high output current and minimized saturation losses sets new power references in the car-radio field, with unparalleled distortion performances.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Panasonic
MPN	TDA7560 / C1A00000021
Model	TDA7560 / C1A00000021
Country/Region of Manufacture	Japan
