Tdk Lambda Linear Switching Power Supply Model: Nv11t000hfm (rohs Compliant)

US $39.99

Modesto, California, United States
Jan 29th

Open on mobile:
QR code

I cannot offer support for this item, I would just like to clear out the inventory in my warehouse. This model is enclosed with a fan. I will throw in three cables that came with the power supply. Here are some of the technical stats from the TDK Lambda website: Model NV175 Input Voltage range: - 90 - 264VAC (47 - 63Hz, 440Hz with reduced PFC) Inrush Current: A &lt;40A at 25°C and 264VAC input, Cold Start Power Factor Harmonics: - EN61000-3-2 Compliant (0.97 typical) Regulation Total: - 1%; Including Line (for 90-264VAC input change), Load (for 0-100% load change) and Cross (for 0-100% load change on any other output) regulation Ripple &amp;amp; Noise: mV 1% or 50mV (Which ever is greater) Efficiency - Up to 90%, configuration dependant Minimum Load: A None Over-current Protection: - &gt;105% Over voltage Protection: V CH1 &amp;amp; CH2, 120-130%, Cycle AC line to reset Over temperature Protection: - Yes Hold Up Time (Typ): ms &gt;16ms at 90VAC Input Leakage Current (max):?A 123?A 120VAC 60Hz, 257?A 240VAC 60Hz, &lt;300?A 264VAC 63Hz (Type Test results) Remote Sense: - On Outputs CH1 &amp;amp; CH2, 0.5V compensation maximum DC Good: - CH1 Only, High on Fail (90% of nominal ±5%) Remote On/Off (Specify N option): - -N1 or -N2 option: TTL level high = Off, -N3 or -N4 option: open circuit = Off (except standby) Operating Temperature (1)(7): - 0 to +70°C. Derate linearily to 50% load from 50°C to 70°C Storage Temperature: - -40 to +85°C Humidity (non condensing): - 5 - 95% RH Cooling: - Forced air, 2m/s from input to output (Approx 10 CFM) Isolation: (4) - Input to Ground 2.3kVDC, Input to Output 4.3kVDC, Output to Ground 200VDC Vibration (non operating): - Conforms to MIL-STD-810E, Method 516.5, Pro I, IV, VI; EN60068-2-6, IEC68-2-6 Shock: - Conforms to MIL-STD-810E/F, Method 514.4, Pro I, Cat 1,9; EN60068-2-27, EN60068-2-47, IEC68-2-47, IEC68-2-47, JIS C0041-1987 Safety Agency Approvals: - UL/CSA/IEC/EN 60950-1, UL/CSA/IEC/EN 60601-1, UL/CSA/IEC/EN 61010-1, CE Mark for LVD Immunity: - EN61000-6-2:2001, EN61000-4-2, -3, -4, -5, -6, -8, -11 Conducted Emissions and Flicker: - EN55022 Class B (per CISPR.22), EN61000-3-3 Radiated Emissions (2): - EN55022 Class A (per CISPR.22) Weight (Typ): g 250g Size (without cover): (3) in 3” x 5” x 1.25”; N option version 3.7” x 5” x 1.2

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Unused Power Supply from a Steris Ceiling Plate Set. New in box and still sealed in Static Shielding Bag.”
