Technicraft Nike Waveguide Assembly Army P/n 9151046 Nsn 5985-00-822-0568

US $11.00

Farmingdale, New York, United States
Jun 9th

Open on mobile:
QR code

TECHNICRAFT NIKE WAVEGUIDE ASSEMBLY P/N TS-57204 ARMY P/N 9151046 NSN 5985-00-822-0568 NOS CONDITION. 14 DAY WARRANTY FOR COMPLETE REFUND US GOVT PRICE 2013 $175.00/EA Name Value CROSS-SECTIONAL SHAPE STYLE INTERNAL, RECTANGULAR EXTERNAL, RECTANGULAR TUBING WALL CONSTRUCTION STYLE CORRUGATED SINGLE TUBING SEGMENT FLANGE QUANTITY 2 FLANGE INSIDE WIDTH 0.620 INCHES MINIMUM FIRST FLANGE AND 0.624 INCHES MAXIMUM FIRST FLANGE FLANGE INSIDE HEIGHT 0.309 INCHES MINIMUM FIRST FLANGE AND 0.313 INCHES MAXIMUM FIRST FLANGE FLANGE OUTSIDE WIDTH 1.297 INCHES MINIMUM FIRST FLANGE AND 1.327 INCHES MAXIMUM FIRST FLANGE FLANGE OUTSIDE HEIGHT 1.297 INCHES MINIMUM FIRST FLANGE AND 1.327 INCHES MAXIMUM FIRST FLANGE FLANGE INSIDE DIAMETER 0.985 INCHES MINIMUM THIRD FLANGE FLANGE DEPTH 0.298 INCHES MINIMUM SECOND FLANGE AND 0.328 INCHES MAXIMUM SECOND FLANGE FLANGE CONNECTING HOLE DIAMETER 0.144 INCHES MINIMUM ALL FLANGES ALL CONNECTION FACILITIES AND 0.147 INCHES MAXIMUM ALL FLANGES ALL CONNECTION FACILITIES VOLTAGE STANDING WAVE RATIO 1.10 MAXIMUM OPERATING PRESSURE 30.0 POUNDS PER SQUARE INCH GAGE WAVEGUIDE OUTSIDE WIDTH 0.702 INCHES NOMINAL WAVEGUIDE INSIDE WIDTH 0.620 INCHES MINIMUM AND 0.625 INCHES MAXIMUM WAVEGUIDE INSIDE HEIGHT 0.309 INCHES MINIMUM AND 0.314 INCHES MAXIMUM WAVEGUIDE OUTSIDE HEIGHT 0.388 INCHES MINIMUM AND 0.394 INCHES MAXIMUM WAVEGUIDE LONGER OFFSET DISTANCE 3.312 INCHES NOMINAL FLANGE CONNECTING FACILITY AND QUANTITY 4 UNTHREADED HOLE ALL FLANGES ALL CONNECTION FACILITIES FLANGE STYLE CHOKE TYPE FIRST FLANGE WAVEGUIDE OFFSET DISTANCE 1.032 INCHES NOMINAL FLEXIBILITY FLEXIBLE SINGLE TUBING SEGMENT MATERIAL COPPER ALLOY ALL TUBING SEGMENT AND FLANGE PRECIOUS MATERIAL AND LOCATION INTERNAL SURFACES SILVER PRECIOUS MATERIAL SILVER III STYLE DESIGNATOR BEND TYPE FSC APPLICATION DATA ANTENNAS,WAVEGUIDES,AND RELATED EQUIPMENT

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second, or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	TECHNICRAFT
MPN	ARMY P/N 9151046
Model	TS-57204
Country/Region of Manufacture	United States
