Technolas Femtec 520f Workstation 2010

US $8500

Sarajevo, Ilidza, Sarajevo, Bosnia and Herzegovina
Jun 9th

Open on mobile:
QR code

Refurbished FEMTEC Workstation **Shipping fees do not include installation. International shipping is available for this equipment, please inquire about pricing for detailed shipping quotes to your location..** Brief description: Laser source, optics and mechanical elements Surgical microscope LCD Monitor and keyboard for data input Shear force sensor and respective display Integrated video camera for live monitoring Patient bed Uninterruptable power supply (UPS); integrated into system Technical Specifications: Laser Type: Femtosecond solid state laser Pulse Repetition Rate: 40 kHz for IntraCOR/ 80 kHz for customFLAP Pulse Length: Approx. 600 fs, typically Wavelength: In range 1025 - 1060 nm Pulse Energy: < 4 µJ Required Power: 230VAC ~ 50/60Hz Power Consumption: Max. 16A (max. 3KVA) Software modules included: customFLAP™ module: for generating LASIK flaps Diameter: from 6 to 9.5 mm* Flap Thickness: up to 200 µm Hinge Position: superior, inferior, nasal, temporal and selectable 5° steps Rim Cut Angle: from 60 to 120° Hinge Angle: from 30 to 60° ICRS customSHAPE™ module: for performing tunnel cuts as a preparation for insertion of Intra-Corneal Ring Segments Outer Diameter: from 5 to 9.5 mm* Tunnel Width: max. 2 mm Depth: max. 500 µm PKP customSHAPE™ module: for performing penetrating keratoplasty Diameter: from 3 to 9.5 mm * Depth: max. 1550 µm Rim Shapes and Styles: Standard, Top-Hat, Mushroom, Orientation Teeth, Polygon, Marking LKP customSHAPE™ module: for performing anterior lamellar keratoplasty Diameter: from 3 to 9.5 mm * Bed Cut Depth: max. 400 µm Rim Shapes and Styles: Standard, Top-Hat, Mushroom, Orientation Teeth, Polygon, Marking FLEK customSHAPE™ module: for performing posterior lamellar keratoplasty Diameter: from 3 to 9.5 mm * Bed Cut Depth: max. 400 µm Rim Shapes and Styles: Standard, Polygon AK customSHAPE™ module: for performing astigmatic keratotomy Cutting Type: one or two AK cuts Radius: max. 4.75 mm * Arc Length: in 1° steps Depth: max. 600 µm INTRACOR module: currently for presbyopia correction * depending on desired depth, rim cut angle and other procedure parameters
