Tecnoelettra Te806 - Generator Automatic Control Panel

US $2200

Guaynabo, Puerto Rico, United States
Jun 2nd

Open on mobile:
QR code

Electronic board for commandand protection of generators with changeover switch The TE806 board control and protect in automatic or manual mode generators and command the changeover switch. It’s a reliable and very simple board. All the controls and commands are indicated by leds and by clear graphic design. Box project assures an IP65 protection and by high quality components, it permits a secure working also in critical ambient conditions. RS232 port (included on the board) permits a quick board setup by an optional programmation key (1571824). By a software you can prepare and save different configurations then you can download them from PC to the key; later you can use this key alone to transmit your setup inside the TE806 board. Simply to use Display 4 ciphers with Led 7 segmens 9 function button 17 indication led 15 alarms 1 Output RS232 with protocol Modbus RTU 10 electrical measures 7 digital inputs 7 programmable relay outputs 7 programmable analog inputs Special functions: Start at distance Stop at distance SCR EJP TE806 1571826 Codes 1571826 standard version + RS232 1571824 Dedicated software + programmation key Keyboard 1. Start 2. Stop 3. Manual button 4. Automatic button 5. Network teleructor button 6. Group teleructor button 7. Reset/esc 8. Test 9. Measures selection Display: Network measures 1. Vac 2. Kva 3. Hz Display: Load measures 1. Ampere Display: Measures and general information 1 Active alarm Display: Generator measures 1. Vac 2. Ampere 3. Kva 4. Hz 5. Battery tension Vdc 6. Working hour Alarms: 1. High engine temperature (digital sensor) 2. Low oil pressure (digital sensor) 3. Low fuel level (digital sensor) 4. High Battery voltage 5. Low battery voltage 6. Batterycharger alternator fault 7. Mechanical fault 8. Low engine speed / low generator frequency 9. High engine speed / high generator frequency 10. Starting failure 11. Emergency stop 12. Low generator voltage 13. Gigh generator voltage 14. Remote stop active 15. Generator overload
