Tek Awg710 Opt 02 4gs/s Arbitrary Waveform Generator - Works Fine!

US $5,250.00

  • Lake Forest, California, United States
  • Jan 29th
Open on mobile:
QR code
TEK AWG710 Opt 02  4GS/s Arbitrary Waveform Generator - Works Fine! TEK AWG710 Opt 02  4GS/s Arbitrary Waveform Generator - Works Fine! Features: 4.0 GS/s Sample Rate Simulates Real-world Signals Up To 2.0 GHz 2 Markers With 1.6 ps RMS Jitter Deliver Ultra-stable Timing to the Device-under-test (DUT) 16 M or 32 M Point Record Length Provide Longer Serial or Rotational Media Data Streams 8-bit Vertical Resolution for Precise Signal Replication EZ Function Generator Mode Allows Quick Creation and Edit of Sine, Square, Triangle, Ramp, Pulse and DC Waveforms Waveform Quick Editor with 300 fs Edge Timing Resolution Delivers Output Edge Control with Near Real-time Precision Real-time Sequencing Creates Infinite Waveform Loops, Jumps, Patterns and Conditional Branches GPIB and LAN Interfaces Option 02 - Extended Bandwidth Output: Amplitude – 500 mVp-p to 1.0 Vp-p into 50 O. Resolution – 1 mV. DC Accuracy – ±(2.0% of amplitude + 2 mV). Offset – No function. Filter – No function. DC Offset Accuracy – 0 V ±10 mV (waveform data = 0). Pulse Response – (–1 and 1 waveform data, at 1.0 Vp-p). Rise Time – (10% to 90%): <175 ps. Fall Time – (10% to 90%): <175 ps. Output Impedance – 50 O. Auxiliary Outputs This unit passes the extensive internal self tests. Some waveforms were left on the internal hard disk and one is shown both on the display and also on the oscilloscope. See photos.  Offered as working, tested.
