Tektronix 1002b Oscilloscope

US $250.00

Cumming, Georgia, United States
Jan 29th

Open on mobile:
QR code

TEKTRONIX TDS 1002B 40 MHZ DIGITAL STORAGE OSCILLOSCOPE USED... GOOD WORKING CONDITIONS TDS1001 TDS1002 TDS1012 TDS2002 TDS2012 TDS2014 TDS2022 TDS2024 Display Monochrome LCD Color LCD Channels 2 2 2 2 2 4 2 4 Bandwidth 40 MHz 60 MHz 100 MHz 60 MHz 100 MHz 100 MHz 200 MHz 200 MHz Sample Rate 1 GS/s 2 GS/s Record Length 2.5 k Points per Channel Time Base Range 5 ns to 50 s/div 2.5 ns to 50 s/div Vertical Sensitivity 2 mV to 5 V/div Auto-set Menu Standard on all models Ext. Trigger Standard on all models FFT Standard on all models Pulse Width Trigger Standard on all models. Selectable Range from 33ns to 10 sec Automatic Measurements 11 Automatic Measurements standard on all models Probe Check Wizard New Probe Check Button standard on all models Trigger-Signal Freq. Readout Standard on all models Specifications Acquisition Modes Peak Detect High frequency and random glitch capture. Captures glitches as narrow as 12 ns (typical) using acquisition hardware at all time/div settings from 5 is/div to 50 s/div. Sample Sample data only. Average Waveform averaged, selectable: 4, 16, 64, 128. Single Sequence Use the Single Sequence button to capture a single triggered acquisition sequence at a time. Trigger System (Main Only) Trigger Modes Auto, Normal, Single Sequence. Trigger Types Edge (rising or falling) Conventional level-driven trigger. Positive or negative slope on any channel. Coupling selections: AC, DC, Noise Reject, HF Reject, LF Reject. Video Trigger on all lines or individual line, odd/even or all fields from composite video or broadcast standards (NTSC, PAL, SECAM). Pulse Width (or Glitch) Trigger on a pulse width less than, greater than, equal to, or not equal to a selectable time limit ranging from 33 ns to 10 s. Trigger Source 2-channel models CH1, CH2, Ext, Ext/5, AC Line. 4-channel models CH1, CH2, CH3, CH4, Ext, Ext/5, AC Line Trigger View Displays trigger signal while trigger view button is depressed. Trigger Signal Frequency Readout Provides a frequency readout of the trigger source. Cursors Types Voltage, Time. Measurements [?]T, 1/[?]T (frequency), [?]V. Measurement System Automatic Waveform Measurements Period, Frequency, +Width, –Width, Rise Time, Fall Time, Max, Min, Peak-to-Peak, Mean, Cycle RMS. Waveform Processing Operators Add, Subtract, FFT. FFT Windows: Hanning, Flat Top, Rectangular 2048 sample points. Sources 2-channel models: CH1 – CH2, CH2 – CH1, CH1 + CH2. 4-channel models: CH1 – CH2, CH2 – CH1, CH3 – CH4, CH4 – CH3, CH1 + CH2, CH3 + CH4. Autoset Menu Single-button, automatic setup of all channels for vertical, horizontal and trigger systems with undo autoset. Autoset Menu for Multiple Signal Types Signal Type Autoset Menu Choices Square Wave Single-cycle, Multi-cycle, Rising or Falling Edge Sine Wave Single-cycle, Multi-cycle, FFT Spectrum Video (NTSC, PAL, SECAM) Field: All, Odd or Even Line: All or Selectable Line Number Display Characteristics Display Monochrome models 1/4 VGA, backlit passive LCD with adjustable multi-level contrast and inverse video selectable from front panel. Display Color models 1/4 VGA, passive color LCD with color on black background with adjustable multi-level contrast. Interpolation Sin(x)/x. Display Types Dots, vectors. Persistence Off, 1 sec, 2 sec, 5 sec, infinite. Format YT and XY. Environmental and Safety Temperature Operating: 0 °C to +50 °C. Nonoperating: –40 °C to +71 °C. Humidity Operating and Nonoperating: Up to 90% RH at or below +30 °C. Operating: Up to 60% RH up to 50 °C. Nonoperating: Up to 60% RH up to 55 °C. Altitude Operating and Nonoperating: Up to 3,000 m. Electromagnetic Compatibility Meets Directive 89/336/EEC, amended by 93/68/EEC, meets or exceeds EN55011 Class A Radiated and Conducted Emissions; FCC 47 CFR, Part 15, Subpart B, Class A; Australian EMC Framework, demonstrated per Emission Standard AS/NZS 2064; Russian GOST EMC regulations. Safety UL61010-1, CSA61010-1, IEC61010-1, EN61010-1. Physical Instrument Dimensions 12.75 in.(w) x 5.96 in.(h) x 4.90 in.(d) 323.8 mm(w) x 151.4 (h)mm x 124.5 (d)mm Instrument Weight 4.4 lbs. (2.0 kg) 4.9 lbs. (2.2 kg) w/ accessories Shipping Dimensions 18.75 in.(w) x 10.50 in.(h) x 9.00 in.(d) 476.2 mm(w) x 266.7 (h)mm x 228.6 (d)mm Standard Accessories Probes P2220 200 MHz 10X to 1X Switchable Passive Probes (one per channel). Documentation User manual. NIM/NIST Traceable Certificate of Calibration. Recommended Accessories TDS2CMAX Communication Module (GPIB, RS-232, Centronics-type Printer Port) TDS2CMAX includes: TDSPCS1 OpenChoice® PC Communication Software RS-232 cable (012-1651-00) Programmers manual TDS2MEM1 Storage Memory and Communication Module (RS-232, Centronics-type Printer Port) TDS2MEM includes: Type 1 CompactFlash memory card (156-9413-00) CompactFlash to USB Memory Card Reader (119-6827-00) TDSPCS1 OpenChoice PC Communication Software RS-232 cable (012-1651-00) Programmers manual 1 Not compatible with TDS1001 or TDS2004.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Tektronix
Channels	2
Model	1002B
