Tektronix 1103 Probe Power Supply Nr!

US $45

Holliston, Massachusetts, United States
Jan 29th

Open on mobile:
QR code

Used Tektronix 1103 Probe Power Supply. Probe supply voltages check out ! Tektronix 1103 probe power supply Power cord Features & Benefits 1103 Powers up to Two Probes For Use with P6205, P6243, P6245, P6246, P6247, P6248, P6249, P6330, P6701B, P6703B, P5205, P5210, ADA400A, and TCP202 on other than TekProbe BNC Interfaced Scopes*1 Overload Protected 1103 Applications High-speed Digital Systems Design ECL GaAs MOS: CMOS; FastCMOS; BiCMOS; TTL Component Design/Characterization Amplitude levels Aberrations Propagation Delay and Timing Bandwidths and Rise Times Educational Research Manufacturing Engineering and Test TekProbe BNC™ Interface The 1103 is an accessory power supply that provides external power to TekProbe BNC Interface probes. The 1103 allows customers to use probes requiring TekProbe interface power with any oscilloscope or digitizer that does not provide TekProbe BNC power. The 1103 offers two independently controlled channels consisting of a TekProbe BNC interface input, a voltage offset control (providing variable offset or no offset) and BNC signal output. The offset control supplies a voltage, adjustable via the front panel control. This offset control is available for TekProbe BNC probes with this capability. These include: P6235, P6245, P6246, P6247, P6248, P6249, and P6330. *1 The characteristics for TekProbe BNC Interface probes are subject to change when used with the 1103 TekProbe Power Supply. Bandwidth, Rise-time, Propagation Delays will generally differ from the advertised probe only specification. These are dependent upon: 1) the cable length from the output BNC connector to the oscilloscope input, 2) the instrumentation input impedance the output BNC is being connected to, and 3) any additional adapters required to properly interface to the test instrumentation. To use TekProbe BNC Interface probes on the 11800, CSA800, TDS8000, CSA8000 or any non-TekProbe BNC interface test instrumentation requires an 1103 TekProbe Power Supply, an SMA Male to BNC Female adapter, a 50 ? BNC cable and if required a 50 ? feedthrough termination. Paypal Welcomed. Fixed shipping of $15 in the lower 48 via USPS Priority mail. Will ship internationally. Thank you for looking and good luck ! Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...

Type

0.5W Terminator
