Tektronix 2336 Two Channel Portable Oscilloscope 100mhz, Two Probe, Low Hours

US $325.00

Seattle, Washington, United States
Mar 14th

Open on mobile:
QR code

Fully Tested and Functional with Two New 100Mhz probes Want a rugged, working, fully function potable scope? This is the one you are looking for! This 2336 from Tek has all the features you need, 100Mhz, dual traces, dual time base, delayed sweep, external trig, LCD for DELTA TIME measurement, all in one rugged aluminum case ...... I did a full functional test in all modes according to Tektronix's service manual and all calibration settings still are well within tolerance. The vertical and horizontal amps are fully calibrated with crystal-based Oscilloscope Calibrator and function generator. The pictures show dual traces with different amplitude on CH1/CH2 with CH2 inverted or not inverted. This scope operates with a sharp, bright trace with plenty of brightness in reserve; no burn spots. All controls/buttons operated normally, very smooth without intermittent problem. Photos are of the actual instrument you will receive and show it's overall good operating/physical condition. The delta time LCD is not in perfect condition but still readable as you can see from the picture. What are includes: Tektronix 2336 100 MHz Oscilloscope Two new 1x/10x switchable probes Power cord Leather porch on top Tek 2335 Manual (very similar to 2336) I usually ship the same day or next business day after payment. DESCRIPTION The 2336 Dual Trace Oscilloscope comes with rugged design, light weight, and an easy-to-use front panel make this a very versatile oscilloscope. Useful for high speed logic and digital applications, the 2336Oscilloscope is both compact and lightweight for ultra-portability. This scope is designed for on-site troubleshooting but feels just as comfortable in the lab. Bandwidth from DC to 100MHz provides the resources necessary to fulfill most general applications. Sensitivity of 5 mV to 5 V/div with variable sweep speeds from 0.5 sec to 50 ns/div; X10 magnifier extends maximum sweep rate to 5 ns/div. Features logically laid-out controls for quick setups and operator convenience and a unique flip-top cover for protection of both front-panel and controls. Main features of the Tektronix 2336 Oscilloscope: DC to 100 MHz bandwidth, 2 Channels with Delayed Sweep capability Lightweight, easy to use Trace brightness controls for both the mains sweep and for delayed sweep Two input channels ±2% accuracy 2 mV/div to 5V/div input sensitivity on dual input channels; 50V/div with 10X probe 50 ns/div to 0.5 sec/div sweep rates, fastest sweep rate to 5 ns/div with X10 mag 10:1 variable hold off range DELTA TIME measurement on LCD Advanced trigger system Delayed sweep measurements Clear, bright CRT $5 package/handling for a well packed shipment included in the total shipping cost. Local pick up is available and free. Guarantee Terms: This item is guaranteed to power on & has no known functional Issues. If the item does not power on (DOA) or is functionally defective, you may qualify for a refund. In such a case, you must contact me within 7 days after you received it. Thanks for looking!

“Fully function, verified, Calibrated, and adjusted to the best possible condition. I have more than 20 different Scopes on sell. Please check out my other scopes.”

Brand	Tektronix
Bandwidth	100 MHz
Type	Analog
Model	2336
Channels	2 Channel
