Tektronix 2465b 400mhz Oscilloscope No Reserve!!

US $700

Southlake, Texas, United States
Jun 9th

Open on mobile:
QR code

This auction is for a Tektronix 2465B 400MHz Oscilloscope. This scope powers up but is not functioning properly and missing some knobs. The Tektronix 2465B Oscilloscope is a four-channel oscilloscope with a bandwidth of 400MHz. Sensitivity is 2 mV at 400MHz. Risetime on all channels is 0.875 ns. The instrument has a sweep speed of 500 ps/Div. It has Volts and Time cursors with on-screen readout. Input is switchable between 1 Mohm and 50 ohm. On-board capture allows you to digitize, store and recall waveforms or analyze them on your PC. It also has a 20 ps Time Interval Resolution. Other features include Auto Setup, Set-Up Sequencing and Cursor After Delay. The analog display allows gray scaling and persistence, whereby faster signals appear fainter than slower signals. And when an event only occurs occasionally in a repetitive signal, the anomaly will fade quicker and look dimmer than the rest of the waveform, which can provide critical information when analyzing complex designs. The 2465B also offers a real time display that responds instantly to changing signal conditions. Since it doesn't have to acquire and then process signal information before displaying it like a digital scope, it can trigger on many more waveforms per second. And with a complete selection of trigger modes, the 2465B can display any signal regardless of its complexity. The Tektronix 2465B Oscilloscope allows fast and precise measurements. The instrument features 400MHz bandwidth at probe tip 500 ps/div sweep rate 2 mV/div vertical sensitivity 500MHz minimum triggering bandwidth Four independent channels 25 Automated Measurements Front Panel Auto Setup Storage
