Tektronix 5000 Series Main Power Supply Assembly Rc 2869-00

US $840

  • Tucson, Arizona, United States
  • May 23rd
Offered for your consideration is a Tektronix 5000 Series Power Supply assembly comprising: xfrmr 120-0821-00 CCA RC-2869-00 CCA 388-3012-00 This is the main power supply -- generates all power forms except for the high voltage (which is a separate CCA).  Operates from nominal 117 VAC line, 60 cps.  Output voltages are:   Precision regulated   +200  +30  +15  +5  -15  -30  VDC  with ripple of 2 mV or less.  Condition: Looks good. All harness wiring is still in place. No obvious signs of overheating or component tinkering. One of the fuse clips has a wire wrapped around it - not obvious why. (Too cheap to buy a fuse, maybe?) There are a few slightly bent header leads resulting from sloppy storage, but nothing major. Untested, but priced accordingly.  A Tek5440 oscilloscope manual will be included, containing the schematic, alignment/calibration procedure, and parts listing.  If you don't need it for a 'scope, this would make a high quality experimenter's bench supply.   +15  -15  for op amps and  +5 VDC  for digital logic.   10 lbs
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Tektronix
