Tektronix 7b50 Time Base 100 Mhz, Refurbished

US $25.00

Melrose, Massachusetts, United States
Jan 29th

Open on mobile:
QR code

Tektronix 7B50 Time Base 100 MHz Functionality has not been verified, AS-IS Triggering to 100 MHz 50 ns/div to 5 s/div 5 s/div with X10 MULTIPLIER The 7B50 and 7B51 Time Base units are recommended for use with the 7400, 7500, 7600 and Storage FAMILIES to provide bandwidth/sweep speed compatibility. However, the 7B50 and 7B51 may be used in any 7000-Series mainframe. They are identical units except in two particulars. In combination, they provide a delaying-sweep mode in operation; the 7B51 being the DELAYING SWEEP and the 7B50 the DELAYED SWEEP. The 7B50 also has a horizontal amplifier input for uncalibrated X-axis deflection from an external source. The calibrated TIME/DIV range is from 5 ns/div to 5 s/div. The 5 ns/div rate is otained with the X10 MAGNIFIER. Triggering control is very flexible with 12 push-button positions to program MODE, method of COUPLING, and SOURCE. For routine applications, hands-off triggering is accomplished by actuating the three upper-most push-button switches: INT SOURCE, AC COUPLING, and P-P AUTO MODE -- the most commonly used combination. The P-P AUTO MODE provides a baseline trace in the absence of a signal and a triggered trace at any position of the LEVEL/SLOPE control when a signal of 0.5 div or greater is present. Except for the selection of + or - SLOPE, this mode is completely automatic. The other triggering positions are useful for specific applications. The triggering frequency range is from DC to 100 MHz, selectable within that range by the method of COUPLING. AC LF REJ attenuates undesirable trigger components below 30 kHz (60 Hz would be almost totally rejected); AC HF REJ attenuates high-frequency components (above 50 kHz) which can cause triggering problems during low-frequency applications. SINGLE-SWEEP functions with lighted READY indicators and manual reset are associated with the trigger MODE controls. For delaying-sweep operation, the 7B51 (occupying the A horizontal channel) contains the DELAY TIME MULTIPLIER and control circuitry to release the 7B50 DELAYED SWEEP (B horizontal channel) at a predetermined point during the delaying sweep. After release, the delayed sweep can be programmed to begin immediately or wait for the next trigger event. Both units can be used singly in all 7000-Series mainframes, or in combination to add the delaying-sweep function. Independent dual-sweep operation is possible only in mainframes with two horizontal amplifiers using CHOP or ALT modes. PO Boxes/APOs require USPS shipping, may experience longer lead times. 6.25% Sales Tax for shipping to Massachusetts Terms and Conditions Have a Question? Send us a message (Contact Seller). We are shipping from just north of Boston, MA in the United States. For international customers, do not assume a product will work in your country due to various International Voltage requirements. Ask first if you are not sure. Warranty (Refurbished Items/Open Box/Surplus): 5 day Right of Return. If the item is found to be defective, contact us to be issued an RMA. Warranty Returns do not apply to listings that indicate: requires parts, needs repair, or as-is in the title and/or description. In case of returns, buyer is responsible for all shipping fees. (Domestic or International) International Shipping Terms: * International customers are responsible for all shipping charges, including any duties or taxes that may be enforced by their respective country. * USPS is the most economical shipping method for international customers. With this often comes a slightly delayed lead-time or erratic tracking information. We ask for your patience, and we will do the best we can to see you get your shipment quickly and accurately. Feedback: We appreciate your Positive feedback. We leave feedback for buyers as soon as our transactions complete. If you have any problems with the sale, we will do anything within reason to correct or improve your experience. If negative feedback is left prior to an attempted resolution, we reserve the right to accept that as the final resolution. We will not accept a return or issue a refund. *Note Estimated Delivery time above. Please contact us if you require specific details, or have a required delivery date. Please contact us for shipping rates to any overseas US territories including: Northern Mariana Islands, Guam, Puerto Rico, Palau, U.S. Virgin Islands and American Samoa.
