Tektronix 80A02 EOS/ESD PROTECTION MODULE *TESTED*, US $610 – Picture 0
Tektronix 80A02 EOS/ESD PROTECTION MODULE *TESTED*, US $610 – Picture 0

Tektronix 80a02 Eos/esd Protection Module *tested*

US $610

  • Albany, Oregon, United States
  • Nov 25th
Open on mobile:
QR code
TEKTRONIX 80A02 EOS/ESD PROTECTION MODULE The 80A02 EOS/ESD Isolation module protects the sampling bridge of Tektronix DSA8300 1 electrical sampling module inputs from damage due to electro-overstress (EOS) and electrostatic discharge (ESD) from circuit boards and cables. The 80A02 is for applications such as electrical TDR circuit board testing and cable testing where large static charges can be stored in the DUT. 1Also compatible with DSA8200, TDS/CSA8200, TDS/CSA8000B, and TDS/CSA8000 sampling oscilloscopes. Key features Single-channel electrostatic discharge (ESD) and electro-overstress (EOS) damage protection for Tektronix DSA8300 electrical sampling modules Plugs into and is powered from sampling mainframe Compatible with Tektronix extender cables <37 ps reflected rise time when used with 80E04 or SD24 electrical sampling TDR modules This item is in very good condition. Pulled from a working system. Has been in storage for the past 24 months.  Item comes with 3 terminations, Instruction Sheet, Carry case, and 14 day warranty. Shipping: Item will be shipped using USPS Priority Flat Rate Medium Box. Any Questions, Please contact me. Thank you
