Tektronix 80e10 50 Ghz True Differential Tdr / Sampling Module - Dsa8200 Dsa8300

US $47,500.00

Culver City, California, United States
Jan 29th

Open on mobile:
QR code

Tektronix 80E10 50 GHz True Differential TDR / Sampling Module - CALIBRATED! You are bidding on a Tektronix 80E10 50 GHz True Differential TDR / Sampling Module with Remote Samplers and a fresh calibration performed by Tektronix. The 80E10 is a dual-channel Time Domain Reflectometry (TDR) sampling module that provides up to 12 ps incident and 15 ps reflected rise time. Each channel of these modules is capable of generating a fast step for use in TDR mode and the acquisition portion ofthe sampling module monitors the incident step and any reflected energy. The polarity of each channel’s step can be selected independently. This allows for differential or common mode TDR or S-parameter testing of two coupled lines, in addition to the independent testing of isolated lines. The independent step generation for each channel allows true differential measurements, which ensures measurement accuracy for differential devices. The 80E10 and 80E08 are small form factor, fully integrated independent 2-meter remote sampler systems, enabling location of the sampler near the DUT and ensuring the best signal fidelity. The modules characterize crosstalk by using TDR steps to drive one line (or line pair for differential crosstalk) while monitoring a second line (or line pair) with the other channel (or another module for differential crosstalk). The "filter" function on the Tek 8200 and 8000 Series mainframes can be used with TDR or crosstalk measurements to characterize expected system performance with slower edge rates. All modules have independent incident step and receiver deskew to remove the effect of measurement fixtures and probes, enabling faster and easier de-embedding of test fixtures. The 80E10 sampling modules provide anacquisition rise time of 7 ps, with up to 50 GHz user-selectable equivalent bandwidth (with 50, 40, and 30 GHz settings). When the user employs these modules with Tektronix IConnect TDR andVNA software, he or she can acquire up to 1,000,000 data points and obtain up to 50 GHz differential, mixed mode, and single-ended S-parameters. THE TEK 80E10 TDR / SAMPLING MODULE HAS A LIST PRICE OF $65,000 USD!! Features: - Up to 50 GHz Bandwidth and 5 ps Measured Rise Time - Lowest Noise for Analysis – 50 GHz: 600 ?V,

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	Tektronix
Model	80E10 TDR / Sampling Module
