Tektronix Awg710 Arbitrary Waveform Generator 2 Ghz 4 Gs/s ,400 Mhz Function G.

US $840

  • Diamond Bar, California, United States
  • May 28th
Tektronix AWG710 Function Arbitrary Waveform Generator to  2 ghz 4 GS/s Tested! , and 400 mhz function generator. Last calibrated by tektronix in 2013.   So  the arbitrary waveform generator requires you to put them on disk and load them from the disk, you can download them online or use your own files. it has 4 gs/s and has option 2 which takes it from 1.2 ghz to 2 ghz capability. it also has a full blown function generator built in as wellthat goes to 400 mhz and includes the usual sine, square, sawtooth aka ramp, triangle , pulse and DC, that alone is worth an easy 1500$ - 2000$ alone.  nice large color screen. all buttons and lcd / knob work flawlessly. I cant find any problems with this unit. takes about 1 minute or 2 to startup and its ready to go! tested with scope as pictured. comes with a 30 day money back guarantee! Come try it out in person at my lab  in Diamond Bar CA, near los angeles.  The AWG710 combines world-class signal fidelity with ultra high-speed mixed signal simulation, a powerful sequencing capability and graphical user interface with flexible waveform editor, to solve the toughest measurement challenges in the disk drive, communications and semiconductor design/test industries.  Features:  4.0 GS/s Sample Rate simulates real-world signals up to 2.0 GHz  2 Markers with 1.6 psRMS jitter deliver ultra-stable timing to the device-under-test (DUT)  16 M or 32 M Point Record Length provide longer serial or rotational Media data streams  8-bit Vertical Resolution for precise signal replication  Analog Bandwidth to 2 GHz (Opt 02, calculated based on Rise Time) provides the highest signal fidelity of all high-speed AWGs  EZ Function Generator Mode allows quick creation and edit of Sine, Square, Triangle, Ramp, Pulse and DC Waveforms  Waveform Quick Editor with 300 fs edge timing resolution delivers output edge control with near real-time precision  Real-time Sequencing creates infinite waveform loops, jumps, patterns and conditional branches  GPIB and LAN (10/100Base-T) interfaces  9095764320 paul
