Tektronix Fg 502 Function Generator Plug-in, Works Great. Fully Functional

US $160.00

  • Seattle, Washington, United States
  • Jan 29th
Open on mobile:
QR code
TEKTRONIX FG 502 Function Generator SN: B038050 Photos are of the actual instrument you will receive and show it's overall good operating/physical condition. It is fully tested and verified in good working condition. This plug in works in a Tek. TM 501, TM503, TM 504, TM 506, and TM 5006 series Module power supply. Generated low distortion sine, square, triangle, positive and negative pulse, and ramp wave forms from 0.1 Hz to 11 MHz Range 0.1 Hz to 11 MHz <0.5% sine wave distortion 0-5V Output into 50? 0-10V Output open circuit Variable DC offset square wave trigger is available at front panel Voltage controlled frequency (VCF) input controls the output frequency from external voltage source. The output frequency can be swept above or below the selected frequency to a maximum of 1000:1 depending on the polarity and amplitude of the VCF input and the selected frequency An external gate input allows the generator to operate for the duration of an externally applied gating signal. This mode provides either a single cycle output, or a train of preselected wave forms, depending on the gating signal width and the frequency setting. Guarantee Terms: This item is guaranteed to power on & has no known functional Issues. If the item does not power on (DOA) or  is functionally defective, you may qualify for a refund. In such a case, you must contact me within 14 days after  you received it. Thanks for looking!
Condition Used :
An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes “Fully function, verified, Calibrated, and adjusted to the best possible condition.”
