Tektronix Mdo3104 1 Ghz Mixed Domain Oscilloscope, 4 Channel Plus Logic Analyzer

US $12,000.00

West Jordan, Utah, United States
Jul 5th

Open on mobile:
QR code

You are bidding on a very slightly used Tektronix MDO3104 Oscilloscope. The Tektronix MDO3104Mixed Domain Oscilloscope is the ultimate 6-in-1 integrated oscilloscope that includes an integrated spectrum analyzer, arbitrary function generator, logic analyzer, protocol analyzer, and digital voltmeter/counter. The Tektronix MDO3104is completely customized and fully upgradable. At the core of the TektronixMDO3104 is a world-class oscilloscope, offering comprehensive tools that simplify each stage of debug – from quickly discovering anomalies and capturing them, to searching your waveform record for events of interest and analyzing their characteristics and your device’s behavior. To debug a design problem, first you must know it exists. Every design engineer spends time looking for problems in their design - a time-consuming and frustrating task without the right debug tools. Digital phosphor technology provides you with fast insight into the real operation of your device. The fast waveform capture rate – greater than 280,000 wfm/s with FastAcq – gives you a high probability of quickly seeing the infrequent problems common in digital systems: runt pulses, glitches, timing issues, and more. There are four waveform palettes available in FastAcq acquisition mode to further enhance the visibility of rarely occurring events. Intensity grading is used to indicate how often rare transients are occurring relative to normal signal characteristics. The Temperature palette uses color-grading to indicate frequency of occurrence with hot colors like red/yellow indicating frequently occurring events and colder colors like blue/green indicating rarely occurring events. The Spectral palette uses color-grading to indicate frequency of occurrence with colder colors like blue indicating frequently occurring events and hot colors like red indicating rarely occurring events. The Normal palette uses the default channel color (like yellow for channel one) along with gray-scale to indicate frequency of occurrence where frequently occurring events are bright. The Inverted palette uses the default channel color along with gray-scale to indicate frequency of occurrence where rarely occurring events are bright. Infinite or variable persistence choices determine how long waveforms stay on the display, helping you to determine how often an anomaly is occurring. Triggering - Discovering a device fault is only the first step. Next, you must capture the event of interest to identify root cause. To enable this, the Tektronix MDO3104 contains over 125 trigger combinations providing a complete set of triggers - including runt, logic, pulse width/glitch, setup and hold violation, serial packet, and parallel data. With up to a 10 M record length, you can capture many events of interest in a single acquisition for further analysis while maintaining high resolution to zoom in on fine signal details. Wave Inspector, the industry’s best tool for waveform navigation and automated search, enables you to find events of interest in seconds. Zoom and pan - A dedicated, two-tier front-panel control provides intuitive control of both zooming and panning. The inner control adjusts the zoom factor (or zoom scale); turning it clockwise activates zoom and goes to progressively higher zoom factors, while turning it counter-clockwise results in lower zoom factors and eventually turning zoom off. No longer do you need to navigate through multiple menus to adjust your zoom view. The outer control pans the zoom box across the waveform to quickly get to the portion of waveform you are interested in Features · 4 Analog Channels · 1 GHz bandwidth · Up to 5 GS/s sample rate · 10 M record length on all channels · >280,000 wfm/s maximum waveform capture rate · Standard passive voltage probes with 3.9 pF capacitive loading and 1 GHz, 500 MHz, or 250 MHz analog bandwidth · Spectrum Analyzer Frequency range - Standard:9 kHz - oscilloscope bandwidth, Optional: 9 kHz - 3 GHz · Ultra-wide capture bandwidth up to 3 GHz · Arbitrary Function Generator (Optional): 13predefined waveform types, 50 MHz waveform generation, 128 k arbitrary generator record length, 250 MS/s arbitrary generator sample rate · Protocol Analyzer (Optional): Serial bus support for I2C, SPI, RS-232/422/485/UART, USB 2.0,CAN, LIN, FlexRay,MIL-STD-1553, and Audio standards, Digital Voltmeter (Free with product registration) 4-digit AC RMS, DC, and AC+DC RMS voltage measurements, 5-digitfrequency measurements · FastAcq high-speed waveform capture rate finds elusive signal anomalies quickly · Wave Inspector Controls provide easy navigation and automated search of waveform data · 33 automated measurements and waveform histograms for simplified waveform analysis · Spectral Analysis Dedicated front-panel controls for commonly performed tasks Logic Analyzer (optionMDO3MSO) The logic analyzer provides 16 digital channels, tightly integrated into the Tektronix MDO3104 oscilloscope's user interface, makes it possible to solve mixed-signal issues easily. Color-coded digital waveform display: Color-coded digital traces display ones in green and zeros in blue. This coloring is also used in the digital channel monitor. The monitor shows if signals are high, low, or are transitioning so you can see channel activity at a glance without having to clutter your display with unneeded digital waveforms. The multiple transition detection hardware shows you a white edge on the display when the system detects multiple transitions. White edges indicate that more information is available by zooming in or acquiring at faster sampling rates. In most cases zooming in will reveal the pulse that was not viewable with the previous settings. If the white edge is still present after zooming in as far as possible, this indicates that increasing the sample rate on the next acquisition will reveal higher frequency information than the previous settings could acquire. MagniVu high-speed acquisition: The main digital acquisition mode on the Tektronix MDO3104 will capture up to 10 M at500 MS/s (2 ns resolution). In addition to the main record, the TektronixMDO3104 provides an ultra high-resolution record called MagniVu which acquires10,000 points at up to 8.25 GS/s (121.2 ps resolution). Both main and MagniVu waveforms are acquired on every trigger and can be switched between in the display at any time, running or stopped. MagniVu provides significantly finer timing resolution than comparable oscilloscopes on the market, instilling confidence when making critical timing measurements on digital waveforms. Auction includes: MDO3104 Oscilloscope 4 TPP1000 Probes MDO 3MSO Logic analyzer upgrade and accessories Storage bag

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Model	MDO3104
Number of Channels	4
Maximum Real-Time Sampling Rate	5 GSa/s
Oscilloscope Type	Digital Storage Oscilloscope (DSO)
Brand	Tektronix
Features	With Probe
Maximum Bandwidth	1 GHz
