Tektronix Probe: P6023 10x Attenuation, 8mohms, 50mhz, 12pf, 1000 Volt

US $170

Lewisville, Texas, United States
Jul 11th

Open on mobile:
QR code

P6023 Jump to navigationJump to searchThe Tektronix P6023 is a 10, 1000 V max. scope probe with 8 M input resistance. "The Type 6023 Probe is a low-capacitance, adjustable attenuation-ratio probe. Attenuation ratio is nominally X 10 and is adjustable over a +/-2.5% range (X9.75 to X 10.25). Designed for use with Tektronix differential amplifiers, the probe offsets the one-percent tolerance resistors used in amplifier attenuators. With the use of two such probes, the attenuator-factor differences of the attenuators can be eliminated and thus increase the common-mode rejection ration of the system. The Type 6023 Probe is especially usefeul with the Type W, 10A1 and 1A7 Differential Comparator Plug-In Units. When used during differential comparator operation, the probe can be accurately adjusted so that voltages can be read directly from the Comparison Voltage helidial and multiplie by the nominal attenuation factor tolerances generally encountered with other probes. During differential preamplifier operation when using two of these probes, the differential capabilities of the plug-in unit are increased and accurate rejection ratio computations can be made. It has variable attenuation and compensation to permit equalizing a pair of these probes on a differential amplifier." Note: Unit has cardboard sleeve that goes over it for protection. We have no way of testing unit without opening the packaging...so sold AS IS NOTE: Unit will be double boxed for safe shipping. ------------------------------------------------------------------------------------------------------------------ Payment Policy: We accept PayPal (via Ebay) Shipping: USA: We use UPS or FedEx Ground as standard shipping method for all 48 States. Ebay GSP is used for limited international shipping. See below. International Shipping: LIMITED INTERNATIONAL SHIPPING INCLUDES: Canada, United Kingdom, Denmark, Finland, Greece, Japan, Sweden, Belgium, France, Ireland, Netherlands, Spain, Italy, Germany, Austria, Israel, Mexico, Switzerland, Norway, Bermuda, South Korea, Taiwan Returns Policy: Our goal is to ensure you are completely satisfied with your purchase. Please Read carefully the description of the item listed for full details before bidding. No returns or exchanges are accepted. -------------------------------------------------------------------------------------------------------------------

“Still in the box. New-old stock(vintage) includes original manual”

Country/Region of Manufacture

United States

Product Type

P6023

Brand

Tektronix
