Tektronix TDS3014B 100 MHz 4-Channel Digital Color Phosphor Oscilloscope (DPO) with Battery, Communications/Video Module, Test Limit and Advanced Analysis Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Tektronix and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is guaranteed to work for 30-days, parts and labor, excluding freight. The Unit's Serial Number Tag Reads: Model Number: TDS3014B Serial Number: B027926 Options and Modules Installed: TDS3BATB - Battery pack for up to 2 hours continuous operation without line power. The instrument must be grounded at all times. TDS3AAM - Advanced Analysis Module TDS3LIM - Limit Testing Module TDS3GV - GPIB, VGA and RS-232 interfaces TDS3FFT - Fast Fourier Transform Module TDS3TRG - Advanced Trigger Applicaiton Module Link to the Datasheet: Tektronix TDS3000B Series Oscilloscope Datasheet Link to the Manual #1: Tektronix TDS3000B Series Oscillscope Manual Link to the Manual #2: Tektronix TDS3000 Series Oscilloscope Programming Manual Link to the Manual #3: Tektronix TDS3AAM Advanced Analysis Module Manual Link to the Manual #4: Tektronix TDS3LIMT Limit Testing Module Manual Features & Benefits: 100 MHz Bandwidth 1.25 GS/s Maximum Real-Time Sample Rate, with sin(x)/x Interpolation 3,6000 wfms/s Continuous Waveform Capture Rate 4 Channels Full VGA Color LCD 25 Automatic Measurements FFT Standard Multi-language User Interface QuickMenu Graphic User Interface for Easy Operation WaveAlert Automatic Waveform Anomaly Detection OpenChoice Solutions Simplify Instrument Control, Documentation and Analysis Applications: Digital Design and Debug Video Installation and Service Power Supply Design Education and Training Telecommunications Mask Testing (with module, not included) Manufacturing Test General Bench Test The TDS3000B Series of Digital Phosphor Oscilloscopes: The TDS3000B Series packs the power of a DPO, digital real-time (DRT) sampling technology, WaveAlert waveform anomaly detection, OpenChoice documentation and analysis solutions, and five application-specific modules into a lightweight, battery-capable design. Benefits of DPO: The TDS3000B Series DPO delivers 3,600 wfms/s continuous waveform capture rate to capture glitches and infrequent events three times faster than comparable oscilloscopes. Some oscilloscope vendors claim high waveform capture rates for short bursts of time, but your oscilloscope needs to deliver these fast waveform capture rates on a continuous basis – saving minutes, hours, or even days by quickly revealing the nature of faults so advanced triggers can be applied to isolate them. In addition, the TDS3000B DPO's real-time intensity grading highlights the details about the "history" of a signal's activity, making it easier to understand the characteristics of the waveforms you've captured. Flexible Features for Every Application: Optional application modules enable you to transform your oscilloscope into a specialized tool for limit testing, telecommunications mask testing, and video troubleshooting. And, with its lightweight, compact size and battery pack, the TDS3000B Series oscilloscope can go wherever it is needed. It weighs only 4.5 kg (9.8 lbs.), with battery installed. Use the optional plug-in thermal printer to instantly document your work, even in the field. TDS3AAM Advanced Analysis Module: Adds extended math capability, arbitrary math expressions, measurement statistics and additional automated measurements. TDS3LIM Limit Testing Module: Offers fast, accurate Go/No Go verification that tested circuits are operating within intended parameters. Specifications: Bandwidth: 100 MHz Channels: 4 Sample Rate on Each Channel: 1.25 GS/s Maximum Record Length: 10K points Vertical Resolution: 9-bits Vertical Sensitivity (/div): 1 mV - 10 V Vertical Accuracy: ±2% Max. Input Voltage (1 MΩ): 150 VRMS CAT I (300 V CAT II with standard 10X probe) Position Range: ±5 div BW Limit: 20 MHz Input Coupling: AC, DC, GND Input Impedance Selections: 1 MΩ in parallel with 13 pF or 50 Ω Time Base: Range (/div): 4 ns - 10 s/div Accuracy: 20 ppm Display Monitor: Color active matrix LCD Acquisition Modes: DPO: Captures and displays complex waveforms, random events, and subtle patterns in actual signal behavior. DPOs are able to provide 3 dimensions of signal information, in real-time; amplitude, time, and the distribution of amplitude over time. Peak Detect: High frequency and random glitch capture. Captures glitches as narrow as 1 ns. WaveAlert: Monitors the incoming signals on all channels and alerts the user to any waveform that deviates from the normal waveform being acquired. Sample: Sample data only. Envelope: Max/Min values acquired over one or more acquisitions. Average: Waveform data from 2 to 572 (selectable) acquisitions is average. Single Sequence: Use SINGLE SEQUENCE button to capture a single triggered acquisition sequence at a time. Trigger System: Main Trigger Modes: Auto (supports Roll Mode for 40 ms/div and slower), Normal. B Trigger: Trigger after time or events. Trigger After Time Range: 13.2 ns to 50 s. Trigger After Events Range: 1 to 9,999,999 events. External Trigger Input: >1 megaohm in parallel with 17 pF; Max input voltage is 150 VRMS. Trigger Types: Edge: Conventional level-driven trigger. Positive or negative slope on any channel. Coupling selections: DC, noise reject, HF reject, LF reject. Video: Trigger on all lines, odd, even or all fields. With TDS3VID or TDS3SDI, trigger on individual lines and on analog HDTV formats (1080i, 1080p, 720p, 480p). Logic: Pattern: Specifies AND, OR, NAND, NOR when true or false for a specific time. State: Any logic state. Triggerable on rising or falling edge of a clock. Logic triggers can be used on combinations of 2 inputs (not 4). Pulse: Width (or GLITCH): Trigger on pulse width less than, greater than, equal to, or not equal to a selectable time limit ranging from 39.6 ns to 50 s. RUNT: Trigger on a pulse that crosses one threshold but fails to cross a second threshold before crossing the first again. Slew Rate: Trigger on pulse edge rates that are either faster or slower than a set rate. Edges can be rising, falling, or either. Comm (requires TDS3TMT): Provides isolated pulse triggering required to perform DS1/DS3 telecommunications mask testing per ANSI T1.102 standard. Alternate: Sequentially uses each active channel as a trigger source. Measurement System: Automatic Waveform Measurements: Period, Frequency, +Width, –Width, Rise Time, Fall Time, +Duty Cycle, –Duty Cycle, +Overshoot, -Overshoot, High, Low, Max, Min, P-P, Amplitude, Mean, Cycle Mean, RMS, Cycle RMS, Burst Width, Delay, Phase, Area*2, Cycle Area*2. Display any four measurements from any combination of waveforms. Or display all measurements with measurement snapshot feature. Measurement statistics*2. Gating: Measurements can be gated using the screen or vertical cursors. Waveform Processing: Deskew: Channel to channel deskew ±10 ns may be manually entered for better timing measurements and more accurate math waveforms. Arithmetic Operators: Add, subtract, multiply, divide, arbitrary math expressions*2. Autoset: Single-button, automatic setup on selected input signal for vertical, horizontal, and trigger systems. Display Characteristics: Waveform Style: Dots, vectors, and variable persistence. Graticules: Full, grid, cross-hair, and frame. NTSC, PAL, SECAM, and vectorscope (100% and 75% color bars) with optional TDS3VID and TDS3SDI video application modules. Format: YT, XY and Gated XYZ (XY with Z-axis blanking available on TDS30X4B only). I/O Interface: Hardcopy Port (Standard): Centronics-type parallel. Ethernet Port (Standard): 10Base-T LAN, RJ-45 female. TDS3GV Communications Module (included): GPIB (IEEE-488.2) Programmability: Full talk/listen modes; control of all modes, settings, and measurements. VGA: Monitor output for direct display on large VGA-equipped monitors. DB-15 female connector, 31.6 kHz sync rate, EIA RS-343A compliant. RS-232-C Interface Programmability: Full talk/listen moldes; control of all modes, settings and measurements. Baud Rate up to 38,400. DB-9 male connector. Hard Copy Capability: Graphic File Formats: Interleaf (.img), TIF, PCX (PC Paintbrush), BMP (Microsoft Windows), and Encapsulated Postscript (EPS). Printer Formats: Bubblejet, DPU-3445, Thinkjet, Deskjet, Laserjet, Epson (9 and 24-pin). Environmental and Safety: Temperature: +5 to +50°C (operating), -20 to +60°C (nonoperating). Humidity: -20% to 80% RH below 32°C, derate to 30% RH at 45°C (operating), 5% to 90% RH below 41°C, derate to 30% RH at 60°C (nonoperating). Altitude: < or = to 3,000 m (operating), < or = to 15,000 m (nonoperating) Electromagnetic Compatibility: Meets or exceeds EN55011 Class A Radiated and Conducted Emissions; EN50082-1; FCC 47 CFR, Part 15, Subpart B, Class A; Australian EMC Framework; Russian GOST EMC regulations. Safety: UL3111-1, CSA1010.1, EN61010-1, IEC61010-1 Physical Dimensions: 375.0 mm W x 176.0 mm H x 149.0 mm D (14.8" x 6.9" x 5.9") Weight: 4.5 kg (9.8 lbs.) Notes: 2: Required TDS3AAM Module - included. For More Pictures Please Click the Following: Picture 2 - Front View Picture 3 - Back View Picture 4 - Side View Picture 5 - Communication Interfaces & Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $25.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 12/16/14 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
