Tektronix Tds3014b 100mhz 4 Channel Oscilloscope

US $1700

Cascinasse, Italy
Feb 26th

Open on mobile:
QR code

Digital Phosphor Oscilloscopes TDS3012 • TDS3014 • TDS3032 • TDS3034 • TDS3052 • TDS3054 Features & Benefits 500 MHz, 300 MHz, and 100 MHz Bandwidths Sample Rates up to 5 GS/s 2 or 4 Channels Full VGA Color LCD on all Models Built-in Floppy Disk Drive For Easy Storage and Documentation 21 Automatic Measurements Centronics Port Standard on all Models for Quick, Convenient Hardcopies 9-bit Vertical Resolution Multi-Language User Interface QuickMenu User Interface Mode for Quick, Easy Operation Optional Modules for RS-232, GPIB, LAN or VGA Communication Ports Advanced Triggers, such as, Glitch, Width, and Logic Standard on 4 Channel Models Telecommunications Mask Testing (TMT) Fast Fourier Transform (FFT) for Frequency and Harmonic Analysis Standard on 4 Channel Models Extended Video Application Module Support for Active Probes, Differential Probes, and Current Probes that Provide Automatic Scaling and Units Applications Telecommunications Manufacturing (Telecom Mask Test Application Module for Pass/Fail Compliance of ITU-T G.703 and ANSI T1.102 [Up to STS-1 Rates] Standards) Digital Design and Debug Video Design and Service (Video Application Modules Offer Line Count, HDTV and Custom Video Trigger, Video Display Graticules, SDI to Analog Video Conversion with Composite and Component Outputs, Video Picture Identification and Vectorscope) Industrial Electronic Design Power Supply Design Connected Instrumentation (10Base-T LAN, GPIB and VGA Modules with RS-232) Highly Mobile Environments (Optional Battery Pack for Convenient Use in the Field or Away from the Bench) The TDS3000 Series of Digital Phosphor Oscilloscopes The TDS3000 oscilloscopes are the lowest priced, most portable Digital Phosphor Oscilloscopes (DPOs). Now every design engineer and technician can take advantage of the tremendous benefits of DPOs. DPOs deliver a new level of insight that makes dealing with complex signals simple. DPOs display, store, and analyze, in real-time three dimensions of signal information: amplitude, time, and distribution of amplitude over time. BENEFITS OF DPO DPOs have an intensity graded color display that provides information about the frequency of occurrence of signal amplitudes and widths. This helps the user locate and characterize waveform anomalies that can be elusive on traditional Digital Storage Oscilloscopes. The fast update rate of DPOs also makes it easier to capture and display infrequent waveforms or waveform variations. QUICK TO LEARN AND QUICK TO USE The TDS3000 Series graphical user interface offers a new operating mode called QuickMenu. This quick access user interface makes the main oscilloscope controls accessible with a push of a single button. Included with every scope is an On-Line Tour disk that runs in the oscilloscope. This disk gives an overview of the product's operation and capabilities. FLEXIBLE FEATURES FOR EVERY APPLICATION The portable form factor allows the instrument to go wherever it is needed. The Communication and Application Modules enable the instrument to be configured for specific applications or upgraded without returning it to the manufacturer. The TekProbe® Level II interface provides power to a range of application specific accessories. APPLICATION MODULES With the application module concept, the TDS3000 Series can be easily adapted to the needs of the user. These modules are easily installed by the user. At power on the scope indicates which modules are installed. Currently, there are five application modules available for the TDS3000 Series - a telecommunications mask test module, an FFT module, an advanced trigger module, a 601 digital video module and an extended video module. In addition, there are three communication modules available - a 10Base-T LAN/RS-232 module, a GPIB/RS-232 module and a VGA/RS-232 module. Centronics port is standard. TDS3TMT - TELECOMMUNICATIONS MASK TESTING MODULE When this module is installed in the TDS3000 Series scope, the TDS3000 DPO becomes a Pass/Fail test instrument for telecommunications standard compliance testing. ITU-T G.703 (DS0, DS1, E1, Clk Interface, DS2, E2, E3, and DS3 rates) standards supported ANSI T1.102 (DS1, DS1A, DS1C, DS2, DS3, and STS-1 rates) standards supported Custom mask editing also available using WaveStar™ software for oscilloscopes V2.3 Properly terminate your device under test with Communication Signal Adapters Use TDS3GM (GPIB) or the NEW TDS3EM (LAN) communication modules to program the TDS3000 for automated testing TYPICAL APPLICATION OF TMT MODULE When testing network line cards in manufacturing, one of the most important considerations is throughput! The combination of DPO waveform throughput and hardware assisted mask testing results in breakthrough test speeds for mask testing on single and multiple channel devices.

Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...

Channels
