Tektronix Tds5104 1ghz, 5gsa/s, 4ch Digital Oscilloscope

US $4000

Oceanside, California, United States
Aug 4th

Open on mobile:
QR code

This is a Surplus Auction This auction is for surplus inventory. These are excess units we have in inventory that we are looking to liquidate. See the description to the right for more details. Auction Terms California Sales Tax applies to CA residents Personal or Company Check (will delay shipment until check clears) Certified Funds (Sameday shipment) PayPal ~ Online Payment Option Tektronix TDS5104 1GHz, 5GSa/s, 4ch Digital Oscilloscope Serial No: B040981 Unit does not complete boot up sequence. Sold as-is Please see pictures. Repair Determination: Does not complete boot up sequence *Return Policy* All units sold will have void seals attached. Please verify your unit matches the description in the auction prior to opening units to attempt any repairs. No returns will be approved for buyers who have broken the void seals. A picture of intact void seals will be required. Manufacturer Description: The Tektronix TDS5104 oscilloscope is a graph-displaying device – it draws a graph of an electrical signal. In most applications, the graph shows how signals change over time: the vertical (Y) axis represents voltage and the horizontal (X) axis represents time. The intensity or brightness of the display is sometimes called the Z axis. The Tektronix TDS5104 oscilloscope's simple graph can tell you many things about a signal, such as: the time and voltage values of a signal, the frequency of an oscillating signal, the “moving parts” of a circuit represented by the signal, the frequency with which a particular portion of the signal is occurring relative to, other portions, whether or not a malfunctioning component is distorting the signal, how much of a signal is direct current (DC) or alternating current (AC) and how much of the signal is noise and whether the noise is changing with time. Features: 4 independent 1 GHz Channels 5 GS/s Maximum Real-time Sample Rate 400K Record Length 100,000 wfms/s Maximum Waveform Capture Rate Trigger: Edge, Video, Glitch, Width, Window, Timeout, Transition, State Trigger Delay by Time - 16 ns to 250 seconds Trigger Delay by Events - 1 to 10,000,000 Events. Waveform Measurements Amplitude-Amplitude, High, Low, Max, Min, Peak-Peak, Mean, Cycle Mean, RMS, Cycle RMS, Positive Overshoot, Negative Overshoot. Time - Rise Time, Fall Time, Positive Width, Negative Width, Positive Duty Cycle, Negative Duty Cycle, Period, Frequency, Delay. Combination - Area, Cycle Area, Phase, Burst Width. Histogram-related (optional) - Waveform count, Hits in box, Peak hits, Median, Maximum, Minimum, Peak to Peak, Mean (µs), Standard Deviation (sigma), µ+1 (sigma), µ+2 (sigma), µ+3 (sigma). Waveform Processing/Math Arithmetic - Add, subtract, multiply and divide waveforms. FFT - Magnitude. Vertical Units - Magnitude: Linear, dB, dBm. Window Functions - Rectangular, Hamming, Hanning, Kaiser-Bessel, Blackman-Harris, Gaussian, Flattop2, Tek Exponential. Industry-leading Suite of Advanced Triggers Built-in Printer (Optional) CD-RW Drive (Optional) Interoperability with Tektronix Logic Analyzers Built-in Floppy Disk Drive For Easy Storage and Documentation National Test Equipment, Inc. 1935 Plaza Real Oceanside, CA 92056

“Unit does not complete boot up sequence. Sold as-is Please see pictures.”

Number of Channels

MPN

TDS5104

Model

TDS5104

Brand

Tektronix

Maximum Real-Time Sampling Rate

5 GSa/s

Maximum Bandwidth

1 GHz
