Tektronix (tek) Dpo7104/5rl Digital Phosphor Oscilloscope, 1 Ghz, 4 Ch

US $3000

Irving, Texas, United States
Jun 3rd

Open on mobile:
QR code

Tektronix (Tek) DPO7104 Digital Phosphor Oscilloscope, 1 GHz, 4 CH Key Features & Specifications 3.5 GHz, 2.5 GHz, 1 GHz, and 500 MHz bandwidth models Up to 40 GS/s real-time sample rate on one channel, up to 20 GS/s on two channels, and up to 10 GS/s on three or four channels Up to 500 megapoint record length with MultiView Zoom™ >250,000 wfms/s maximum waveform capture rate with FastAcq™ FastFrame™ segmented memory acquisition mode with >310,000 waveforms per second capture rate User-selectable bandwidth limit filters for better low-frequency measurement accuracy provide quick insight into signal characteristics Connectivity USB Host Ports on the front and side panels for quick and easy data storage, printing, and connecting USB peripherals Integrated 10/100/1000BASE-T Ethernet port for network connection and Video Out port to export the oscilloscope display to a monitor or projector Microsoft® Windows 7 64-bit operating system for easy connectivity and integration into your environment LXI Class C compliant Description 500 MHz,1 GHz, 2.5 GHz, and 3.5 GHz models Up to 500 Mpoints record length Up to 40 GS/s sample rate 53 automated measurements and FFT analysis Serial bus triggering and analysis options for I2C, SPI, RS-232/422/485/UART, USB 2.0 Automated serial analysis for MIPI DSI-1 and CSI-2 Comprehensive verification including serial debug and compliance with jitter and eye validation, power analysis, MIPI D- PHY, Ethernet, USB and wideband RF analysis Standard removable hard disk drive Large 12.1/ XGA display with touch screen Windows 7 Ultimate 64-bit operating system Options installed: 5RL 250 M max, 50 M/ch MATsolutions "Buy with Assurance" Please Contact Nicole Augspurger at MATsolutions for Questions regarding this listing at (877)621-1280.
