Tektronix Tek Hfs9dg1 Hfs 9dg1 Data Time Generator Card For Hfs9003 & Hfs9003

US $200.00

Vista, California, United States
Jan 29th

Open on mobile:
QR code

Avalon Equipment Corporation Data Time Generator Card Manufacturer Model# Tektronix HFS9DG1 Condition Good, Operates Properly Return Policy 14-Day Warranty Details Tek HFS 9DG1 Data Time Generator combines the capabilities of a data time generator, pulse generator, and switch matrix in a single instrument. As part of the HFS 9000 Stimulus System, the data time generator can deliver complete data and timing signals to the circuit under test. Within the data time generator, every output is capable of producing any type of data and formatting - not just data and pulses. Complete control over rise and fall times, widths, and voltage levels on all data is provided. Because of the unique digital architecture, this data time generator can place an edge anywhere, even delaying waveforms across cycle boundaries. Controls for the data time generators are accessed in several menus. Controls that affect the pulse parameters of the data time generator are in the Pulse menu. It generates five different types of signals: Pulse, NRZ (Non-Return to Zero), RZ (Return to Zero), R1 (Return to One), and DC. Compatibility: HFS9003, HFS9009 Specifications Frequency range: 50kHz to 630MHz Channel deskew (Chan Delay) resolution: 1ps Delay (Lead Delay, Trail Delay) adjustment resolution: 1ps Pulse width adjustment range: Zero to (one period x 65,536) inclusive Pulse width accuracy: 1% of width +50 -75ps Maximum high level: +5.0V Minimum low level: –2.5V Maximum amplitude: 3.00V Minimum amplitude: 0.01V Level resolution: 0.01V Operation when terminated through 50? to –2V: Output levels will be approximately 1 V more negative than the values programmed, specified, and displayed. Actual output levels more negative than –2 V may cause malfunction. Level accuracy specifications do not apply when terminating to –2 V. Both true and complement outputs must be terminated to the same voltage Operation when terminated to high impedance loads: Output level range will double until certain internal limits are achieved. Since the programmed, specified, and displayed output levels do not match the actual output levels, level accuracy specifications do not apply when terminating to a high impedance load. Because of the larger voltage swings associated with doubled level range, output transition time specifications do not apply when driving a high impedance load. Output limits: One high limit and one low limit may be enabled or disabled together Cosmetic condition: good. Accessories Included: HFS9000-Series manual on CD (has operating info for HFS9DG1), front panel patch wire. Warranty begins upon receipt of unit. Warranty void if tamper seals broken. Local pick up okay. Our phone#: 888-542-8256 We are in Vista, California (a community of San Diego). **** Attention Non-US Bidders! **** Some items may be subject to Export Control Restrictions that will prevent us from shipping to your country. All items to be shipped to foreign countries will first need to be verified by Avalon before they are shipped. Items that are subject to export controls may require additional documentation and information from the bidder or may not be allowed to ship at all. Foreign bidders are STRONGLY encouraged to review U.S. export controls for items you are bidding on PRIOR to bidding. Go to www.bis.doc.gov and follow the procedures listed if this applies to you. **** International Shipping **** International shipments are shipped via the eBay Global Shipping Program. We ship the item to the eBay freight forwarder, who then transships it to its destination. Once the item leaves the forwarder, it is then the responsibility of eBay. That is, if it is lost or damaged, eBay is liable for it, and any shipping claims must be handled through eBay. The international shipping amount will be computed by eBay and will be shown on the auction page. In the listing, the buyer sees Estimated Shipping Charges and Estimated Import Charges which will be charged when eBay submits the invoice. We do not ship internationally by any method other than the eBay Global Shipping Program! Payment Terms Shipping Policies Avalon Equipment Corporation accepts the following forms of payment: Check (will delay shipment until check clears) i-Escrow (escrow fees to be paid by buyer) PayPal (preferred method - item shipped quickly) MasterCard/Visa/American Express CA Residents add applicable county sales tax WA Residents add 8.8% Sales Tax TX Residents add 8.25% Sales Tax Including Shipping Every attempt is made to ship on the same day of payment. Shipping charges are added to final bid price. Shipping can be billed to customer's account if wished (domestic only); contact us for details. Most items are InstaPak foamed to ensure that equipment arrives in the same condition as shipped. Unit(s) are guaranteed to be in good working order upon your receipt. Calibration not included unless explicitly stated in auction. CLICK FOR LARGER VIEW:
