Tektronix Tekscope Ths720a 100mhz Dual-channel Oscilloscope Ths720

US $795.00

Toledo, Ohio, United States
Jul 14th

Open on mobile:
QR code

The Following Items Are Included: Tektronix TekScope THS720A 100MHz Oscilloscope 500MS/s (BC# 38020-L/T*) (2) Agilent N2862B Voltage Probe Sets (2) Agilent Hard Point Test Leads AC Adapter/Charger Power Cord User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Tektronix TekScope THS720A HandHeld 100MHz Dual-Channel Oscilloscope 100MHz SCOPE / DMM/ 500MS/s Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 1 YEAR WARRANTY The Tektronix THS720A oscilloscope is a graph-displaying device – it draws a graph of an electrical signal. In most applications, the graph shows how signals change over time: the vertical (Y) axis represents voltage and the horizontal (X) axis represents time. The intensity or brightness of the display is sometimes called the Z axis. The Tektronix THS720A oscilloscope's simple graph can tell you many things about a signal, such as: the time and voltage values of a signal, the frequency of an oscillating signal, the “moving parts” of a circuit represented by the signal, the frequency with which a particular portion of the signal is occurring relative to, other portions, whether or not a malfunctioning component is distorting the signal, how much of a signal is direct current (DC) or alternating current (AC) and how much of the signal is noise and whether the noise is changing with time. The THS720A shares measurement features with the THS730A, THS720P Oscilloscope/DMMs, which are ideal for electronic applications. Features & Benefits 100 MHz Bandwidth 500 MS/s Sampling Rates per Channel Two Channels and Dual Digitizers External Trigger 334 Digit DMM with Datalogger Roll Mode Extra Bright Backlit Display 8 ns Glitch Capture Independently Floating Isolated Oscilloscope and DMM Channels for Safety Full Floating Measurement Capability up to 600 VRMS Advanced Trigger – Delay, Pulse and Video (Line Count and Field Select) 21 Automatic Measurements RS-232 Programmability/ Communications NiCd Battery and AC Adapter Applications Field or Bench Electronic Troubleshooting Floating (Nongrounded) System Measurements Oscilloscope Functions Bandwidth: 100 MHz Sample Rate (each channel): 500 MS/s Channels: Two Sensitivity: 5 mV to 50 V/div (to 500 V/div with 10X probe). Position Range: ±10 div. DC Gain Accuracy: ±2%. Vertical Resolution: 8-Bits. Record Length: 2500 points. Horizontal Accuracy: ±200 ppm. Roll Mode: 0.5 s/div. Autorange: User-selectable. Trigger Modes: Auto, Normal. Trigger Types: Edge, Pulse, Video, External. Video Trigger Formats and Field Rates: Odd field, even field and line. External Trigger Input: 5 MHz TTL compatible. Waveform Processing: Add, Subtract, Multiply, Calculate Watts = V x I. Waveform Storage: 10 waveforms. Acquisition Modes: Sample, Envelope, Average, Peak Detect. Cursor Measurements: delta Volts, Time, 1/ Time (Hz), Degree (phase). Cursor Types: Horizontal Bars, Vertical Bars, Paired (volts @ time). Display System: Interpolation: Sin(x)/x. Format: YT and XY. Mode: Vector, Dot, Vector Accumulate, Dot Accumulate. DMM Specifications DC Voltage Ranges: 400.0 mV to 880 V. DC Volts Accuracy: ±(0.5% of reading + 5 counts). True RMS AC Voltage Ranges: 400.0 mV to 640 V. Maximum Float Voltage: 600 VRMS CAT II, each channel (probe dependent). Resolution: 4000 count, 3-3/4 digits. AC Volts Accuracy: ±(2% of reading + 5 counts)./span> Resistance Ranges: 400.0 to 40.00 M. Resistance Accuracy: ±(0.5% of reading + 2 counts); 40 M: ±(2% of reading + 5 counts). Diode Test Range: 0 to 2 V. Continuity Check: Audible tone when < 50 . Modes: Min, Max, , Max-Min, Avg, Hold. Nonvolatile Storage: 10 DMM screenshots. External Trigger Input: 5 MHz TTL compatible. Vertical Zoom Capability: 2X, 5X, 10X. dB Scale: Selectable, referenced from 1 mV to 10 V. dBm Scale: Selectable, referenced from 50 to 600 . General Specifications Setups: 10 front-panel setups. Safety: UL3111-1, CSA1010.1, EN61010-1, IEC61010.1. EMC: Meets Directive 89/336/EEC. Power: NiCd rechargeable battery pack with AC adapter (both included). Battery Life: Approx. 2 hours from full charge. Display: Backlit LCD. Display Resolution: 320 x 240. Physical Characteristics Width: 177 mm Height: 217 mm Depth: 51 mm Weight: Net 1.45 kg Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you!

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	Tektronix
Number of Channels	2
MPN	THS720A
Features	Handheld/ Portable
Oscilloscope Type	Digital Storage Oscilloscope (DSO)
Model	THS720A
Maximum Bandwidth	100 MHz
