Tektronix Ths3024 200mhz Four 4 Channel Oscilloscope Ths-3024 Ths3000

US $4,295.00

Toledo, Ohio, United States
Mar 5th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Tektronix THS3024 200 MHz Oscilloscope (BC# 20126) Tektronix THP0301-M 10x Voltage Probe Kit Tektronix THP0301-B 10x Voltage Probe Kit Tektronix THP0301-G 10x Voltage Probe Kit Tektronix THP0301-V 10x Voltage Probe Kit (2) Tektronix THP0301 Accessory Kits Tektronix THS3000 Installation & Safety Manual Tektronix THS3000 AC Adapter/Power Supply Manual Tektronix THSBAT Rechargeable Battery Pack Manual Accessory Case AC Adapter/Charger Power Cord USB PC Interface Cable User Manual On CD-ROM Strap For Unit Hard Carrying Case BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Tektronix THS3024 HandHeld 200 MHz Four-Channel Oscilloscope This Is A Brand New, Open Box Unit In Perfect Condition! With 4 isolated channels and up to 7 hours of battery life, the lightweight THS3000 Handheld Oscilloscope Series enables you to safely make floating or differential measurements on your bench or in the field Includes Hard Carrying Case & Accessories As Listed Above! Working Condition: Perfect Condition: Brand New, Open Box Calibrated: Yes Warranty: 90 Day Exchange Warranty Tektronix THS3024 Handheld Oscilloscope With 4 isolated channels and up to 7 hours of battery life, the lightweight THS3000 Handheld Oscilloscope Series enables you to safely make floating or differential measurements on your bench or in the field. Now you can tackle tough environments with the performance you expect from Tektronix - safely and affordably. Accurately measure your signals With up to 200 MHz bandwidth, 4 channels, and 5 GS/s maximum sample rate, no other oscilloscope offers as much bandwidth and sample rate in a portable handheld form factor. The THS3000 Handheld Oscilloscope Series has 10,000 points record length per channel, enabling you to capture more signal information at higher sample rates to clearly see signal details. For applications where it is important to measure slow-changing signals over long time periods, the THS3000 Series offers Roll mode that extends the record length to 30,000 points of signal information. Safely make floating and differential measurements Making accurate and safe measurements on power electronics, power semiconductors, and other electronics applications can be challenging when the signal reference is floating and not referenced to earth ground. When your signal ranges from low voltage to high voltage (kV) or you must use probing techniques that can potentially create ground loops, the problem is compounded. To enable floating measurements, the THS3000 Series is architecturally different than most other oscilloscopes. All input channels are fully isolated from the main chassis and from each other. Additionally the power adapter and USB interface are fully isolated to ensure safe measurements and eliminate the risk of unintentional grounding or accidental short circuits. When configured with the proper probes you can be assured you'll be able to make quick, safe, and accurate measurements. Fast analysis of your device The THS3000 Handheld Oscilloscope Series is packed with analysis tools to help you validate your device's operation and identify issues quickly. With waveform math, you can add, subtract, or multiply any of your signals to investigate instantaneous power or look at gain. Vertical and horizontal cursors allow you to look at a specific point on your waveform for accurate measurements of voltage, current, time, or frequency. With 21 automated measurements, you can make common measurements quickly and accurately. The built-in Fast Fourier Transform (FFT) function allows you to see the frequency spectrum of your signal, revealing signal interference, crosstalk, or switching noise. Find intermittent faults with TrendPlot™ Intermittent faults can be caused by timing errors, temperature changes, environmental influences, or simply broken wiring or connectors. The TrendPlot™ function helps you find those faults by plotting minimum and maximum measurement values over time. You can select up to 4 measurements and plot any combination of voltages, amps, frequency, time, and phase for any or all four inputs, all with time capture information. Automatic capture and data logging of 100 display screens Capturing random or changing signals can often be difficult. The THS3000 Series greatly simplifies any type of waveform data logging by continuously capturing 100 display screens. Each screen capture can include multiple channels and math waveforms, each with its own time stamp. Data capture can also be tailored to specific events by selection of qualified trigger conditions. Playback is quick and easy with the automatic replay of all captured screens or only the screens you select. Waveform limit testing The THS3000 Series can automatically monitor your signals and output Pass or Fail results by judging whether the input waveform is within predefined boundaries. User selections can include testing one or all input channels and automatic recording of Pass or Fail data. Data can easily be reviewed using the Replay mode or stored externally to a USB memory device. Complete solution for power measurements For performing power measurement on motor drives, power converters/ inverters, and power semiconductor devices the THS3000 Series is equipped to handle most common measurements. For basic debugging, the isolated input channels can be used with a variety of voltage and current probes. Each input channel can be configured to match the probe type and attenuation ensuring correct measurements and cursor readings. Four channels allow for easy measurements of three-phase power or simultaneous capture of digital control and power signals. Measurements on power conversion electronics usually require probes with higher voltage ratings. Tektronix offers a passive probe with insulation systems specifically designed for making floating measurements. The standard THP0301-X can measure up to 849 Vp-p (300 VRMS). Optional P5122 probes, when coupled with the THS3000 Series, are suitable for making measurements on 1000 VRMS devices in Category II environments, with a maximum float voltage of up to 600 VRMS relative to earth ground. Intuitive operation The THS3000 Handheld Oscilloscope Series has a front-panel layout and an intuitive user interface which makes the instrument easy to use, reducing learning time and increasing efficiency. For initial setup or for situations where you're constantly changing connection points, the THS3000 Series has a single-button Autoset and Autorange feature which can automatically set up the trigger system and adjust vertical and/or horizontal oscilloscope settings. Easy to use The bright color display makes it easy for you to see the signals you're measuring. Each waveform is color coded and designed to correspond to the colors on the input probe connectors, the front-panel channel selector buttons, and the individual probes which are colored at both ends. By matching the colors during setup you'll be assured you can easily identify your waveforms. For setup assistance user messages are available in 11 user-selectable languages including English, French, German, Spanish, Portuguese, Italian, Japanese, Simplified and Traditional Chinese, Korean, and Russian. Flexible data transfer The THS3000 Series oscilloscopes come with both a USB host and USB mini port located on the side panel enabling you to quickly and easily save instrument settings, screenshots, and waveform data onto a flash device or transfer the data directly to a PC. The THS3000 Series is shipped with the Tektronix OpenChoice® desktop software, allowing you to integrate your new THS3000 Series oscilloscope into existing measurement systems and take advantage of extended functionalities in data acquisition, measurement analysis, and documentation. Versatility and portability for wherever your job takes you With a battery life of 7 hours and a weight of only 4.8 lb. (2.2 kg) the THS3000 Handheld Oscilloscope Series offers ultimate portability. Measurements taken in the lab can now be conveniently correlated with those taken in the field - all on the same instrument. Rated IP41, the THS3000 Series features the ruggedness needed to go beyond the lab and into industrial and field environments. The optional travel kit comes with a hard-sided carrying case and useful accessories allowing you to take the THS3000 Series on the road securely and conveniently. From the lab to the field, the THS3000 Handheld Oscilloscope Series offers you the versatility of using a single, high-performance instrument suitable for a wide range of working environments. Features: 21 automatic measurements Waveform math and FFT spectral analysis Volts, time, frequency, watts cursor measurements Measurement data logging with TrendPlot Waveform pass/fail limit testing Automatic 100 display screens recorder 6 in. (153 mm) bright color display USB device and host support 7 hours of continuous battery operation Applications: Embedded analog and digital design Power devices, power electronics, and power supply design Automotive and avionics design and maintenance Industrial equipment design and installation Field test and service Specifications: Overview Isolated input channels 4 Analog bandwidth (-3 dB) 200 MHz Rise time 1.7 ns Hardware bandwidth limits 20kHz, 20 MHz, or full Float voltage 1000 VRMS CAT II / 600 VRMS CAT III from BNC shell to earth ground Maximum sample rate 5 GS/s (1.25 GS/s 4-ch) Maximum record length (all channels) 10,000 points (30,000 points in roll mode (4 ms to 2 min / div)) Vertical system Input coupling AC, DC Input impedance 1 M? ±1%, 14 pF ±2 pF input sensitivity range 2 mV/div to 100 v/div Vertical resolution 8 bits DC gain accuracy ±2.1% of reading +0.04 x range/div for 5 mV/div to 100 V/div Max BNC input voltage (1 M?) 300 VRMS CAT III from BNC signal to BNC shell Max probe voltage (with standard THP0301-X probe) 300 VRMS CAT III from 10:1 probe tip signal to BNC and reference lead Trace positioning ±4 divisions Horizontal system Time base range (s/div) 1 ns to 4 s Delay time range 1 full screen (12 divisions) of pre-trigger or up to 100 screens (1,200 divisions) of post-trigger Timing accuracy ±100 ppm + 0.04 div Zoom Horizontally expand or compress a live or stopped waveform Trigger System Input source Channel 1, 2, 3, or 4. All input references isolated from each other and earth ground Main trigger modes Auto-level, Auto, Normal, and Single Trigger coupling DC, HF reject, Noise reject (reduces sensitivity) Trigger sensitivity, internal DC coupled 0.5 divisions from DC to 5 MHz at >5 mV/div 1 divisions >5 MHz to 200 MHz Trigger level range Any channel ±4.0 divisions Trigger modes Edge: Positive, negative, or dual slope on any input channel. Coupling includes DC, HF reject, and Noise reject Pulse width: Trigger on channel 1, width of positive or negative pulses (glitches) that are >, <, =, or ? a specified period of time (resolution of 0.01 div with minimum time of 50 ns) Event: Trigger on n-th occurrence of trigger (N selectable from 2 to 99) Video: Trigger on channel 1, line number, all lines, odd, even, or all fields on NTSC, PAL, PAL plus, and SECAM signals Non-interlaced: Trigger on channel 1, high-res non-interlaced video with line frequencies from 14 kHz to 65 kHz Acquisition modes Sample (default) Acquire sampled values Glitch detect Captures high frequency or glitches as narrow as 8 ns from 5 ?s to 120 s / div Averaging Selectable from 2, 4, 8, or 64 waveforms Roll Scrolls waveforms right to left across the screen at sweep speeds slower than or equal to 4 ms/div Data recorder Automatic data logging of 100 triggered records (screens) with date and time stamp. store internally or to a USB device Waveform compare Visually compare against user-definable reference waveforms or perform automatic pass or fail testing of 1 to 4 channels with data logging of test results Automatic setup Autoset Single-button, automatic setup of all channels for vertical, horizontal, and trigger systems Autorange Continuous auto-setup of vertical, horizontal, and trigger systems that track signal changes Waveform measurements Cursors Time, freq (1/T), volts, watts, Rise/Fall time from any input channel or math waveform Automatic measurements 21. Up to 4 can be displayed on-screen at any one time. Measurements include: V DC, V ACRMS, V AC+DC, VPeak Max, VPeak Min, Peak to Peak, A DC, A AC, A AC+DC, Frequency, Rise time (using cursors), Fall time (using cursors), Phase (between any 2 inputs), Positive pulse width, Negative pulse width, Positive duty cycle, Negative duty cycle, dBV, dBm into 50 ? and 600 ? TrendPlot™ Records and graphically displays any 4 automatic scope measurements. store internally or to USB flash drive for recall and analysis Waveform math Arithmetic Add, subtract, and multiply waveforms FFT Spectral magnitude. Set FFT vertical scale to Linear or Logarithmic, and FFT window to Automatic, Hamming, Hanning, or None Display system Display type 6 in. (153 mm) liquid-crystal color display Display resolution 320 horizontal x 240 vertical pixels Waveform style Vectors (dot-join), Dots, Envelope, Variable persistence, Infinite persistence Display format YT and XY Storage memory Reference 4 user-definable reference traces Waveform Stores 30 internal scope records (4 traces each) with screen image and corresponding setup Recording Store 10 internal recordings that can be a 100-screen replay sequence, a roll-mode recording, or a TrendPlot™ measurement recording Screen image Store up to 9 internally or 256 BMP images to an external USB storage drive Real-time clock Time and date stamp of all stored data Input/Output ports USB host port Supports USB mass storage devices USB device port Mini-USB-B connector allows for communication/control of oscilloscope Probe compensator output Side-panel output Amplitude 1.225 V Frequency 500 Hz Kensignton-style lock Side-panel security slot connects to standard Kensington-style lock Software OpenChoice® Desktop Enables fast and easy communication between a windows PC and the THS3000 series. Transfer and save settings, waveforms, and screen images Power source Battery 7 hour, 10.8 v rechargeable Li-Ion battery Battery charging time 5 hours Line power AC power adapter/charger Power source voltage 100 v to 240 v AC ±10% Power source frequency 50 hz to 60 hz Physical characteristics Dimension Height 265 mm (10.5 in.) Width 190 mm (7.5 in.) Depth 70 mm (2.8 in.) Weight Net 2.2 kg (4.8 lb.) Shipping (base model) 4.7 kg (10.4 lb.) Shipping (TK model) 7.8 kg (17.1 lb.) Environmental Enclosure IP 41 according to IEC60529S Temperature Operating: 0 °C to +40 °C (with battery) 0 °C to +50 °C (without battery) Nonoperating: –20 °C to +60 °C Humidity Operating: 0 °C to 10 °C, noncondensing 10 °C to 30 °C, up to 95% relative humidity 30 °C to 40 °C, up to 75% relative humidity 40 °C to 50 °C, up to 45% relative humidity Nonoperating: –20 °C to 60 °C, relative humidity, noncondensing Altitude Operating: Up to 3,000 m (9,843 ft.) Nonoperating: Up to 12,000 m (39,370 ft.) Vibration/Shock Operating: Vibration (Sinusoidal): 3 g max, according to MIL-PRF-28800F, class 2 Shock: 30 g max, according to MIL-PRF-28800F, class 2 Nonoperating: Vibration (Random): 0.03 g2/Hz, according to MIL-PRF-28800F, class 2 Regulatory Electromagnetic compatibility: EN 61326-1:2006, EN 61326-2-1:2006 for emission and immunity Safety: UL61010-1:2004; CAN/CSA C22.2 No. 61010.1-04; EN61010-1:2001, Pollution degree 2; ANSI/ISA-82.02.01 Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. --> This item is subject to a FIXED SHIPPING price. This means that the shipping fee will be the displayed amount for all ship-to destinations shown. This item is eligible for pickup unless otherwise stated. We do not ship to any destinations that are not specified here. Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do/do not cover this cost for all of our US customers. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept payment transactions via our online checkout system! Our checkout process is designed that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through our online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hrs upon receipt of payment from the winning bidder. A Shipment Tracking number will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Terms: All transactions are final. Winning bidder assumes all risk of liability with respect to the purchase of the product. Thank you WE ACCEPT ALL MAJOR CREDIT CARDS Reach your goals with Kyozou eBay Sales Management

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Tektronix
Model	THS3024
